180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
Specifications
Brand Name :
Hongli
Model Number :
HL4000
Certification :
CE,ISO
Place of Origin :
Dongguan,china
MOQ :
1 set
Price :
80,00$-150,000$
Payment Terms :
T/T, L/C
Supply Ability :
100 set per year
Delivery Time :
60-120 days
Packaging Details :
wooden packing
Name :
Copper Rod Continuous Casting Machine
Size :
4000 T
Copper Size :
8-17mm square mm
production speed :
180-220mm/min
motor brand :
siemens
inverter brand :
Yaskawa
main motor :
120kw+120kw
power consumption :
325kwh/ton
oven size :
300-500Kg
Description

4000 Tons Oven Continuous Casting Machine For Oxygen-Free Copper Materials Rod Copper Wire Scrap

About us:
Our factory has been manufacturing extrusion lines for over 20 years ,we also produce copper buncher, cable twisting machine, cable tapping machine, copper drawing machine.Until now we have exported some production lines to Pakistan, iraq,Tunisia, Algerial, Egypt, India, Afghanistan,Nigeria, Sudan, we are still working on other country,

Main brands for our machine

- Motor: SIEMENS, DONGGUAN MOTOR,
- Inverter: YASKAWA, INOVANCE, SIEMENS,
- PLC: Siemens
- Touch Screen: Siemens
- Low-voltage electrical components: Schneider
- Bearings: NSK or SKF
Copper Scrap Solution Comparison
Process Purity Scrap Quantity Product/Purity Main Equipment
CCR >95.2% 10KT-50KT/annually Rod/99.9% Furnace, Casting/rolling, fume treatment
Adding to upcast after refinery >96% 1-3KT/annually Rod/99.9% Refining furnace, Up casting line
Adding to upcast without refinery >99.5% 5-20KT/annually Rod/99.95% Up casting line
Direct Electrolysis >96% <2 KT/a nnually Cathode/99.95% Electrolysis system, water purification
Anode Electrolysis 90-92% 5KT-150KT/annually Cathode/99.97% Refinery furnace, fume treatment,anode caster, electrolysis system, water purification

Summery
The up casting line is one of our strength products, it is the best way of making oxygen free copper rods. With its advantages of flexible capacity and product size, compact process, economic power installation and consumption. The rods of our up casting line are widely used as raw material for continuous extrusion and enameling.
Upward continuous casting oxygen-free copper rod production line (called the plant as follow), it is used for producing the big length shining/bright oxygen-free copper rod, the big length shining oxygen-free copper tube and the big length shining oxygen-free copper flat strip, etc.

Craftwork flow
Cathode copper/Scrap copper → melting furnace → transition chamber → holding furnace → casting machine (crystal molding) → casting rod → take-up device → on sale or further producing
Put the cathode copper into the melting furnace of QL1 compounded furnace straightly. It will be melted into liquid by a frequency inductor. Then the liquid of copper smoothly pass through the transition chamber and will flood into the holding furnace automatically , and then it will be deoxidized by the charcoal covered. The liquid of copper will become a casting rod quickly by the crystallizer of the casting machine in the holding furnace. Then it will be hauled by the double-withdrawal roller of the casting machine. When the casting rod is hauled off, it will be led to take-up device.

180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials

180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials180-220mm/Min Copper Rod Continuous Casting Machine For Oxygen Free Copper Materials
