Specifications
Brand Name :
Spiral Cable
Model Number :
TH-800126
Certification :
UL, CUL, CSA, AWM, CE
Place of Origin :
Dongguan, China
MOQ :
200 PCS
Price :
USD0.12~0.63 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
800,000pcs per month
Delivery Time :
10 days for ready goods
Packaging Details :
200pcs per carton box
Type :
Retractable Cable
Feature :
Repetitive Flexing Resistant, Robotics Use
Rated Temperature :
80 degree
Rated Voltage :
300V
Dimensions :
To be customized per request
Standard :
RoHS Compliant
Description

Repetitive Flexing Resistant Robotics Retractable Cable

Retractable Cable is one of Tongheng main products. Repetitive Flexing Resistant Robotics Retractable Cable can be customized exactly following customers requirement. As the professional manufacturer, Tongheng staff engage to present customer the best quality article. Repetitive Flexing Resistant Robotics Retractable Cable is one of the excellent example. Its remarkable advantage is vey good repetitive flexing resistance for robotics use.

Here below is the product properties:

Feature: Repetitive flexing resistant

Application: Robotics

Oxygen free copper strands conductors.

To be customized per customer request.

Product parameters:

Retractable Cable Conductor Structure Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Conductor Resistance
No/mm mm mm % mm mm Ω/KM(20℃)
2C 7/0.100 0.23 0.80 ≥65 0.76 3.80 381.00
2C 7/0.127 0.23 0.90 ≥65 0.76 4.00 239.00
2C 7/0.16 0.23 1.00 ≥65 0.76 4.10 150.00
2C 11/0.16 0.23 1.10 ≥65 0.76 4.20 94.20
2C 17/0.16 0.23 1.30 ≥65 0.76 4.60 59.40
2C 21/0.178 0.23 1.50 ≥65 0.76 5.00 36.70
2C 34/0.178 0.23 1.80 ≥65 0.76 5.60 23.20
2C 26/0.25 0.23 2.00 ≥65 0.76 7.80 14.60
3C 7/0.100 0.23 0.80 ≥65 0.76 4.00 381.00
3C 7/0.127 0.23 0.90 ≥65 0.76 4.20 239.00
3C 7/0.16 0.23 1.00 ≥65 0.76 4.40 150.00
3C 11/0.16 0.23 1.10 ≥65 0.76 4.60 94.20
3C 17/0.16 0.23 1.30 ≥65 0.76 5.20 59.40
3C 21/0.178 0.23 1.50 ≥65 0.76 5.50 36.70
3C 34/0.178 0.23 1.80 ≥65 0.76 6.10 23.20
4C 7/0.100 0.23 0.80 ≥65 0.76 4.20 381.00
4C 7/0.127 0.23 0.90 ≥65 0.76 4.40 239.00
4C 7/0.16 0.23 1.00 ≥65 0.76 4.70 150.00
4C 11/0.16 0.23 1.10 ≥65 0.76 5.10 94.20
4C 17/0.16 0.23 1.30 ≥65 0.76 5.40 59.40
4C 21/0.178 0.23 1.50 ≥65 0.76 5.90 36.70
5C 7/0.100 0.23 0.80 ≥65 0.76 4.40 381.00
5C 7/0.127 0.23 0.90 ≥65 0.76 4.60 239.00
5C 7/0.16 0.23 1.00 ≥65 0.76 4.70 150.00
5C 11/0.16 0.23 1.10 ≥65 0.76 5.10 94.20
5C 17/0.16 0.23 1.30 ≥65 0.76 5.70 59.40
6C 7/0.100 0.23 0.80 ≥65 0.76 4.60 381.00
6C 7/0.127 0.23 0.90 ≥65 0.76 5.00 239.00
6C 7/0.16 0.23 1.00 ≥65 0.76 5.40 150.00
6C 11/0.16 0.23 1.10 ≥65 0.76 5.70 94.20

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the differentt requirement.
