Scientific Research Fiber Coupled Diode Laser 1470nm 15w
Scientific Research Fiber Coupled Diode Laser 1470nm 15w
Specifications
Brand Name :
BWT
Model Number :
KE70HA5CAN-15.00W
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 Piece/Pieces
Payment Terms :
T/T
Delivery Time :
4-8weeks
Wavelength :
1470nm
Laser type :
Fiber coupled diode laser
Application :
Medical use
Laser power :
15W
Product name :
1470nm 15W Fiber Coupled Diode Laser for Scientific research
Output power :
15w
Description

Scientific Research 1470nm 15w Fiber Coupled Diode Laser

Features:

1470nm wavelength

15W output power

400µm fiber core diameter

0.22NA Optical fiber numerical aperture

Applications:

Cosmetology

Physiotherapy

Surgery

Dentistry

Specifications(25℃)

Symbol

Unit

 KE70HA5CAN-15.00W
Minimum Typical Maximum

Optical Data(1)

 CW Output Power Po W 30 - -
Center Wavelength lc nm 1470±20
Wavelength Shift with Temperature △l/△T nm/℃ - 0.3 -

Electrical Data

 Electrical-to-Optical Efficiency PE % - 16 -
Operating Current Iop A - - 9
Threshold Current Ith A - 0.3 -
Operating Voltage Vop V - - 25
Slope Efficiency η W/A - 3.8 -

Fiber Data

 Core Diameter Dcore µm - 105 -
Numerical Aperture NA - - 0.22 -
Fiber Connector - - - SMA905 -
Thermistor Rt (KΩ)/(25℃) 10±3%
PD PD µA 10 - 1000

Others

 ESD Vesd V - - 500
Storage Temperature (2) Tst ℃ -20 70
Lead Soldering Temp Tls ℃ - - 260
Lead Soldering Time t sec - - 10
Operating Case Temperature (3) Top ℃ 15 - 30
Relative Humidity RH % 15 - 75
Aiming Output Power Pa mW 2 - -
Wavelength λa nm 635±10
Voltage Va V - 2.3 3
Current la mA 45 65

(1) Data measured under operation output at 15W@25

(2) A non-condensing environment is required for operation and storage.

(3) Operating temperature defined by the package case. Acceptable operating range is 15 ~30 ,but performance may vary.

Scientific Research Fiber Coupled Diode Laser 1470nm 15w

Instructions for use

- Avoid eye and skin exposure to direct radiation during operation.
- ESD precautions must be taken during storage, transportation and operation.
- Short-circuit is required between pins during storage and transportation.
- Please connect pins to wires by solder instead of using socket when operation current is higher than 6A.
- Soldering point should be close to the middle of the pins.
- Soldering temperature should be lower than 260℃ and time shorter than 10 second.
- Make sure the fiber output end is properly cleaned before operation of laser. Follow safety protocols to avoid injury when handling and cutting the fiber.
- Use constant current power supply to avoid surge current during operation.
- Laser diode must be used according to the specifications.
- Laser diode must work with good cooling.
- Operation temperature ranges from 15℃ to 30℃ .
- Storage temperature ranges from -20℃ to +70℃.
