Tungsten Carbide Insert Turning Tcmt 090204
Tungsten Carbide Insert Turning Tcmt 090204
Tungsten Carbide Insert Turning Tcmt 090204
Tungsten Carbide Insert Turning Tcmt 090204
Specifications
Brand Name :
BWIN
Model Number :
TCMT16T304
Place of Origin :
China
MOQ :
10pcs/box
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1-10000pcs 7days
Delivery Time :
7 work days
Packaging Details :
Plastic box
Product name :
Tcmt Cnc Carbide Turning Insert
Material :
Tungsten Turning Insert
Workpiece :
Cast iron/Steel/Stainless steel
Usage :
Cnc Tool
Color :
Yellow/Brown/Fuchsia/Black/Two-color coating/Cermet coating
Coating :
CVD PVD
Hardness :
HRC40-60
Feature :
High reliability
Application :
Cnc Lathe Tool
Package :
10pcs/Box
Description

Cnc Carbide Insert Turning Tcmt 090204 090208 110202 110204 110208 16t304 16t308

Quick Detail:

  • Balchas coating
  • Superfine alloy matrix
  • Tough and wear-resistant
  • Strong universality
  • Widely used

Description:

  • The TCMT cnc carbide inserts are made of ultra-fine alloy matrix and Balchat high-quality coating. It has excellent toughness, heat resistance and low chemical affinity. Suitable for processing stainless steel, especially austenitic stainless steel, and low-speed cutting of heat-resistant alloy steel; Stainless steel rough machining universal groove, strong cutting edge, good wear resistance, strong impact resistance. Stainless steel processing realizes stable processing from light cutting to heavy cutting, greatly improving the production efficiency on the processing site.

Specifications:​

Brand BWIN
Model Tcmt090204 Tcmt16t302 Tcmt16t304 Tcmt16t308 Tcmt090202 Tcmt090208
Color Yellow/Brown/Fuchsia/Black/Two-color coating/Cermet coating
Workpiece Cast iron/Steel/Stainless steel
Type Cnc Carbide Inserts
Material Tungsten CNC Carbide Turning Insert
Processing Medium Cutting
Feature

Balchas coating

ne alloy matrix

Tough and wear-resistant
Strong universality
Widely used
Standard ISO
Quantity 10pcs/box
Weight 0.015kg
Package Plastic Box
Customized OEM, ODM

Lead Time:

antity(pieces) 1 - 3000 >3000
Lead time (days) 7 To be negotiated

Tungsten Carbide Insert Turning Tcmt 090204

I(mm)
d(mm)
t(mm)
d1(mm)
09
5.56
2.38
2.5
11
6.35
2.38
2.8
16
9.523
3.97
4.4

Notice:

  • Before use, check the power and stiffness of the machine tool to ensure that the required cutter particle diameter can be used on the machine tool.
  • The tool overhang on the spindle should be as short as possible to reduce the impact load caused by the cutter grain axis and the workpiece position.
  • The correct cutter pitch suitable for this process shall be adopted to ensure that there are not too many blades engaged with the workpiece at the same time during cutting, which may cause vibration. On the other hand, when milling narrow workpieces or milling cavities, it is necessary to ensure that there are enough blades engaged with the workpiece

Applications:

Our cnc carbide inserts could to be processed Alloy steel, Tool steel, carbon steel, stainless steel, Cast iron and Titanium alloy. Working material as following:

Tungsten Carbide Insert Turning Tcmt 090204

FAQ
1. Flank Wear? Higher cutting resistance,Notch wear on flank,Poor roughness of surface, or deterioration of accuracy.
Soft grades,Excessive cutting speed,Small flank angle,Low feed.
Select a higher,wear-resistant grade,Reduce cutting speed,Increase flank angle,Increase feed.
2. Crater Wear? Uncontrolled chip,Poor surface quality,when finishing High speed processing carbon steel
Soft grades,Excessive cutting speed,Excessive feed,The strength of chip breaker Insufficiet.
Change to a higher wear-resistant grade,Reduce cutting speed,Reduce feed,Select a higher strength chip breaker.
3. Chipping? Sudden fracture of cutting edge(rake face and flank),Instability insert life
Toughness insufficient,Excessive feed rate,Strength of cutting edge insufficient,Instability of the tool.
Select a tougher grade,Decrease feed rate,Increase honing of cutting edge(chamfering to rounding),Increase the stability and setting angle
4. Insert Fracture? Cutting resistance increased Poor surface roughness.
Toughness insufficient,Excessive feed rate,Strength of cutting edge insufficient,Instability of the tool.
Select a tougher grade,Decrease feed rate,Increase honing of cutting edge(chamfering to rounding),Increase the stability and setting angle.
5. Plastic Deformation? Variation of dimension Nose wear,cutting edge drape or passivating.when processing alloy steel Poor surface roughness
Soft grade,Excessive cutting speed,Excessive cutting depth and feed rate,Overheat on cutting edge.
Select a higher red hardness cutting material,Decrease cutting speed,Decrease cutting depth and feed rate,Select a higher thermal conductivity cutting material(CVD+sufficient coolant).
6. Build-Up-Edge? Workpiece dissove with Cutting edge Poor surface roughness when finishing,Cutting resistance increased,Cutting soft materials.
Cutting speed too low,Cutting edge obtuse,Unsuitable tool material. Increase cutting speed,Increase rake angle,Select small sticking force.
