Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
Specifications
Brand Name :
TOBO/TPCO/TISCO/VALIN/METAL
Model Number :
Incoloy 625 UNS N06625
Certification :
ISO/PED/TUV/SGS/LR/BV
Place of Origin :
China/Japan/Germany
MOQ :
1 Ton/Tons neogotiationTrial Order
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 Ton/Tons per Week neogotiation
Delivery Time :
delivery time is according to the actual order
Packaging Details :
Wooden Cases
Product Name :
Incoloy 625 UNS N06625 steel plate
Product Type :
Steel Plate
Standard :
AISI, ASTM, BS, DIN, GB, JIS
Grade :
Ni-Cr-Fe alloy
Ultimate Strength (≥ MPa) :
550
Ni (Min) :
38
Elongation (≥ %) :
35
Application :
Nitrate condenser,Steam heating pipes,etc
Length :
1000-12000mm
Description

Incoloy 625 UNS N0665 steel plate JIS, AISI, ASTM, GB, DIN, EN

Quick Details

Place of Origin:
Shanghai, China (Mainland)

 Type:
Nickel plate
 Application:
Nitrate condenser,Steam heating pipes,etc
Grade:
Ni-Cr-Fe alloy
 Ni (Min):
38
 Powder Or Not:
Not Powder
Ultimate Strength (≥ MPa):
550
 Elongation (≥ %):
35
 Model Number:
Incoloy 625
Brand Name: TOBO

Packaging & Delivery

Packaging Details: Wooden Cases
Delivery Detail: delivery time is according to the actual order

Specifications

Incoloy 625 UNS N06625 steel plate:
1)Size:1000mm x 2000mm
2)Thk:1mm-60mm
3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB90

Incoloy 825 UNS NO8825 steel plate :
1)Size:1000mm x 2000mm
2)Thk:1mm-60mm
3)Standard:ASTM B424/ASME SB424,ASTM B906/ASME SB906

Chemical Composition, %

Cr Ni Mo Co + Nb Ta Al Ti C Fe Mn Si P S
20.00-30.00 Remainder 8.0-10.0 1.0 max 3.15-4.15 .40 max .40 max .10 max 5.0 max .50 max .50 max .015 max .015 max

In what applications is Inconel 625 used?

· Aircraft ducting systems

· Aerospace

· Jet engine exhaust systems

· Engine thrust-reverser systems

· Specialized seawater equipment

· Chemical process equipment

Fabrication with Inconel 625

Alloy 625 has excellent forming and welding characteristics. It may be forged or hot worked providing temperature is maintained in the range of about 1800-2150° F. Ideally, to control grain size, finish hot working operations should be performed at the lower end of the temperature range. Because of its good ductility, alloy 625 is also readily formed by cold working. However, the alloy does work-harden rapidly so intermediate annealing treatments may be needed for complex component forming operations. In order to restore the best balance of properties, all hot or cold worked parts should be annealed and rapidly cooled. This nickel alloy can be welded by both manual and automatic welding methods, including gas tungsten arc, gas metal arc, electron beam and resistance welding. It exhibits good restraint welding characteristics.

ASTM Specifications

Pipe Smls Pipe Welded Tube Smls Tube Welded Sheet/Plate Bar Forging Fitting Wire
B444 B705 B444 B704 B443 B446 - - -

Mechanical Properties

Representative Tensile Properties, bar, 1800° F anneal

Temp° F Tensile (psi) .2% Yield (psi) Elongation in 2 “ (%)
70 144,000 84,000 44
400 134,000 66,000 45
600 132,000 63,000 42.5
800 131,500 61,000 45
1000 130,000 60,500 48
1200 119,000 60,000 34
1400 78,000 58,500 59
1600 40,000 39,000 117

Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate


Aerospace ASME SB424 550MPa UNS N06625 Incoloy 625 Plate
