Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Thermofusion Hydraulic Butt Welder PP PE PVDF 63-200mm
Specifications
Description

Thermofusion Butt Fusion Hydraulic Welding Machine Description
Butt fusion welding is the established hot plate welding technique for thermoplastic pipes — one of two main methods for fusion joining polyethylene gas and water pipe. The heating phase (bead-up) involves pressing pipe ends against the heated plate for a set duration. This is followed by the heat soak phase where pressure reduces to just hold the pipe ends on the hot plate, allowing heat absorption into the material. After heat soak, the hot plate is removed and pipe ends are brought together — the dwell time must be minimized. The final phase is welding/cooling, set according to pipe diameter and wall thickness.
Thermofusion Butt Fusion Hydraulic Welding Machine Specification
Product NameThermofusion Butt Fusion Hydraulic Welding Machine
Model
SMD-B200/63H
Pipe size (MM)
63-200MM
ApplicationPE Pipe & Fitting Welding
Heating plate Max. Temperature
270℃
Temp.deviation in surface (170-250 ℃)
≤±7℃
Pressures Adjustable Ranges
0-6.3Mpa
Working Voltage
220V , 50/60HZ , single phase
Heating plate power
1KW
Planing tool power
1.1KW
Hydraulic unit power
0.75KW
Total Power
2.85KW
Weight
106KG
Packing
Cases
3 plywood cases
Volume
0.58 CBM

FAQ

1. ZEMOWELD: based in Hebei, China — comprehensive manufacturer and experienced exporter of thermoplastic welding equipment.
2. Quality: pre-production samples + final inspection.
3. Products: Butt Fusion, Electrofusion, PPR, Automatic, Fittings, Pipe Tools.
4. CE/ISO/BV/SGS/CNAS certified. 40mm to 3000mm range.
5. FOB/CFR/CIF/EXW/FAS/CIP/FCA/CPT/DDP/DDU. Payment: USD/EUR/CNY via T/T, L/C, D/P, D/A, MoneyGram, PayPal, Western Union.
