The 253-0071 Half Arrow Segment is a heavy-duty bucket edge protection component designed for wheel loader buckets. This weld-on half-arrow segment provides enhanced protection for the bucket base edge, reducing wear between adapters and extending bucket service life in demanding loading applications.

Manufactured from high-strength alloy steel and heat-treated for superior durability, the 253-0071 improves bucket penetration, loading efficiency, and wear resistance. It is widely used on 966G, 966H, 966M, 972G, 972H, and 972M wheel loaders operating in quarry, mining, aggregate, and construction environments.

• OEM Part Number: 253-0071
• Half Arrow Cutting Edge Segment
• Weld-On Bucket Protection Design
• High Wear-Resistant Alloy Steel
• Improves Bucket Penetration Performance
• Extends Bucket Lip Service Life
• Superior Impact and Abrasion Resistance
• Suitable for Heavy Loading Applications

The OEM specification lists a thickness of approximately 44 mm and length of 897 mm.

Suitable for:

• 950H
• 962H
• 966G
• 966G II
• 966H
• 966K
• 966M
• 972G
• 972G II
• 972H
• 972K
• 972M

The 253-0071 Half Arrow Segment is ideal for:

• Wheel Loader Buckets
• Mining Operations
• Quarry Loading
• Aggregate Processing
• Heavy Construction Projects
• Material Handling Operations

Half-arrow segments are designed to protect the bucket base edge, improve penetration, and increase loading efficiency while minimizing bucket wear.

• Extends bucket edge service life
• Protects bucket structure from abrasion
• Improves bucket penetration capability
• Reduces maintenance and rebuild costs
• Increases productivity and bucket performance
• Suitable for severe wear applications

• OEM-quality replacement wear parts
• Premium alloy steel casting
• Advanced heat-treatment technology
• Excellent impact and abrasion resistance
• Strict dimensional quality control
• Factory-direct pricing
• Worldwide shipping available

A: The 253-0071 is a weld-on half-arrow segment used to protect the bucket base edge and improve penetration performance on wheel loader buckets.

A: It is commonly used on CAT 966 and 972 series wheel loaders, including 966G, 966H, 966M, 972G, 972H, and 972M models.

A: The half-arrow segment is manufactured from heat-treated alloy steel designed to maintain hardness and provide long wear life.

A: According to your supplied product data, the unit weight is 103 kg.

• 253-0069 Half Arrow End Bit LH
• 253-0070 Half Arrow End Bit RH
• 253-0079 Half Arrow Cutting Edge
• 470-9306 Half Arrow Edge
• 470-9307 Half Arrow Edge
• Wheel Loader Bucket Wear Parts
