RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Specifications
Warranty :
1 year
Customized support :
OEM, ODM
Place of Origin :
Henan, China
Brand Name :
BINGSHENG
Model Number :
BSK-ORP-100
Product name :
Digital ORP sensor
Resolution :
1mV
Data communication :
Rs485(MODBUS-RTU)
Temp measure range :
0.0~60.0℃,≤ 85% RH
Power consumption :
≤ 0.5W
Applicable scope :
Environmental protection, Sewage, Online detection
Type :
ORP Sensor
Price :
Discussion
Description
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Product Description
FEATURES: 1.Adopt solid electrolyte, 0.4MPa pressure.
2.Easy to use without adding electrolyte.
3.Solid electrolyte salt bridge can prevent electrode poisoning effectively, such as S²ˉ,CNˉ.
4.Adopt antifouling annular Teflon liquid junction, hard to clog, long-term online detection.
5.Adopt different sensitive membrane electrode for PH measurement under various conditions. Low inner resistance electrode, fast response and high stability.
6.Adopt standard Pg13.5 screw thread, suitable for piping erection.

Working principle: Electrochemical sensor Applicable scenarios: sewage, river water, secondary water supply, lake water monitoring
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Specification
Product name
Digital sensor
Resolution
±0.01 pH
Accuracy
±0.02pH
Waterproof Rate
IP68


Measurement range
A: Voltage signal (choose one from 0-2V, 0-5V, 0-10V)
B: 4-20mA (current loop)
C: RS485 (standard Modbus RTU protocol, device default address: 01)
Power supply voltage: 7-24V DC (when the output signal is 0-2V, RS485) 12-24V DC (when the output signal is 0-5V, 0-10V, 4-20mA) (Customizable 3.3-5V DC)
Temperature range
Temperature: 0~60℃; Humidity ≤ 85% RH
Power consumption
≤ 0.5W
Cable Length
5m standard cable, other length can be optional;
Guarantee Period
12 months
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Company Profile
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Certifications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Exhibition
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
Shipping&payment
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
RS485 Digital ORP Measurement Electrode for Environmental Protection Applications
