Specifications
Warranty :
1 years
Customized support :
OEM, ODM
Place of Origin :
China
Brand Name :
BS
Product name :
Chloride Ion Selective Sensor
Principle :
industrial on-line electrode method
Output Signal :
Support RS-485, MODBUS protocol
temperature Measurement range :
-10.0~110.0 ℃
Ion concentration Measurement range :
0.000-20000ppm
Resolution :
0.001 ppm;0.1C;
Measurement accuracy :
± 0.5% FS;±0.5C
Working power supply: :
9-27VDC
Temperature compensation :
automatic/manual
MOQ :
5 pieces
Price :
Discussion
Description
Specification
RS485 Online Water Ammonia Calcium Nitrate Nitrite Fluoride Chloride Ion Sensor
specifications
Product Name
online chloride ion sensor

Ion concentration
Measurement range:
0.000-20000ppm
Resolution
0.001 ppm
Measurement accuracy
± 0.5% FS



Temperature
Measurement range
-10.0~110.0 ℃
Resolution
0.1C
Measurement accuracy
± 0.5C
Temperature type
Thermistor NTC10K
Temperature compensation:
automatic/manual
Data transmission
RS-485
MODBUS-RTU communication protocol



Other parameters
Working power supply
9-27VDC
Isolation strength
2500Vrms
Product power
approximately 0.5W
Product material
PPS shell
Installation method
3/4 inch front and rear threads
Application
Industrial water, environmental protection, etc.
Product Description
* Digital sensor, RS-485 output, support MODBUS
* Unaffected by transmission distance for better stability
* Built-in temperature sensor, automatic temperature compensation
Product advantages: 1. Chloride ion single electrode and composite electrode are solid membrane ion selective electrodes, used to test free chloride ions in water, which can be fast, simple, accurate and economical.
2.The design adopts the principle of single-chip solid ion selective electrode, with high measurement accuracy
3.PTEE large-scale seepage interface, not easy to block, anti-pollution Suitable for wastewater treatment in the semiconductor industry, photovoltaics, metallurgy, etc. and pollution source discharge monitoring 4. 1. The patented chloride ion probe, with an internal reference fluid at a pressure of at least 100KPa (1Bar), seeps extremely slowly from the microporous salt bridge. Such a reference system is very stable and the electrode life is longer than the ordinary industrial electrode life.
5. Easy to install: NPT3/4 pipe thread for easy submersible installation or installation in pipes and tanks
6.High-quality imported single chip, accurate zero point potential without drift
7.Double salt bridge design, longer service life.
