Specifications

Pixel Pitch :

1.25mm

LED Packaging :

SMD/COB

Module Dimension(W×H) :

300mm×168.75mm

Module Resolution(W×H) :

240×135

Pixel Density :

640000 pixels/m²

Maintenance :

Front

Brightness :

600cd/m²

Contrast Ratio :

≥3000:1

Viewing Angle(H/V) :

160°/160°

Gray Scale :

13~16bit (Adjustable)

Refresh Rate :

7680Hz

Frame Rate :

50/60Hz

Brightness Level :

0~100% (Manual/Auto/Timing)

Color Temperature :

3000~9500K (Adjustable)

Input Voltage :

100-240V~, 50/60Hz

Max. Power Consumption :

500W/m²

Avg. Power Consumption :

167W/m²

Working Temperature :

-10℃~+45℃

Description

Indoor Control Room Fine Pixel Pitch LED Display

Control room
Technical Specifications

Model	P0.9375	P1.25	P1.5625	P1.875
Pixel Pitch(mm)	0.9375	1.25	1.5625	1.875
LED Configuration	Mini 4in1	SMD1010	SMD1212	SMD1515
Module Resolution(dot) (H x V)	320 x 180	240 x 135	192 x 108	160 x 90
Module Size(mm) (H x V)	300x168.75
Module Maintenance Method	Front
Cabinet Resolution(dot) (H x V)	640 x 360	480 x 270	384 x 216	320 x 180
Cabinet Size(mm) (H x V)	600x337.5x75
Cabinet Material	Aluminum Die-cast
Cabinet Weight (kg/pcs)	6.5kg/pcs
IP Standard (Front / Back)	IP45
Density(Pixels / sqm)	1137777	640000	409600	284089
Brightness Range(nits)	≥600	≥600	≥600	≥600
Brightness Adjustment(Levels)	256
Best View Distance(m)	0.9	1.2	1.5	1.8
Working voltage	110V / 220V
Grey Scale(bits)	13-16
Refresh Rate(Hz)	3840
Frame Rate(Hz)	50 / 60
View Angle(H/V)	140/140
Max. Consumption (w/sqm)	680	680	680	680
Ave. Consumption(w/sqm)	220	220	220	220
Working Humidity	10% - 95%	10% - 95%	10% - 95%	10% - 95%
Working Temperature	-20℃ ~ 55℃
Signal Available	DVI,HDMI,SDI,DP and so on
Life Span(Hours)	100000
Running Files	Text , Animation, Image, Video and so on

Aging test

Control room

References 1

Control room

References 2

Control room

References 3

Control room

References 4

Control room
