Specifications
Product model :
216"
Product Type :
GOB
Size(inch) :
216
Pixel Pitch(mm) :
0.9
Overall Dimension(mm) :
4830.8x2825.4x31'
Net weight(kg) :
285
Average power consumption(kw) :
1.158
Maximum power consumption(kw) :
3.858
Resolution :
3840x2160
Contrast :
15000:1
Grayscale :
13~16bit
Speaker unit :
4 full range units + 2 low frequency units
Speaker maximum power :
120w
Max. sound pressure level :
95dB
Audio frequency domain :
60Hz~20kHz
Refresh Rate :
3840Hz
Brightness :
100~600cd/㎡(Adjustable)
Viewing Angle(H/V) :
165°/165°
Input and output interface :
Input：HDMI2.0 *1、HDMI1.4 *3、USB2.0 *1、USB3.0 *2、Type-C *1、POE *1、RJ45 *1、3.5mm Audio in *1、RS232 *1
Output：HDMI2.0 *1、3.5mm Audio out *2、USB *1
Operating system :
Android13.0，8G + 64G，Cortex-A76 ×4 + Cortex-A55 ×4
Optional Windows System
Cabinet material :
Die-casting magnalium
Installation method :
Mobile Stand , Wall mounting, Ceiling-hanging
Maintenance method :
Front-maintenance
Recommended viewing distance(m) :
≥2.5
Description
Ultra-Low Power LED Display

Experience unparalleled visual clarity and efficiency with our advanced LED display technology. Designed for impactful advertising and dynamic content delivery, this display offers a vivid picture with a wide field of view, all within a strong, lightweight design.

  • Ultra-low power consumption, up to 40% reduction.
  • Strong and lightweight construction for easy handling.
  • Vivid picture quality with a wide field of view.
  • Fast installation with minimal labor.
  • Front and rear maintenance accessibility.

Ideal for: Spectaculars, Street Furniture, DOOH Displays, Digital Signage, and Transit Areas.

NPP-All in one

Technical Specifications
Product model138"168"220"135"162"216"
Product TypeSMDGOB
Size(inch)138168220135162216
Pixel Pitch(mm)1.51.91.21.50.91.2
Overall Dimension(mm)3080x1840x28'3690x2183x28'4910x2869x28'3030.8x1812.9x31'3630.8x2150.4x31'4830.8x2825.4x31'
Net weight(kg)122172296110155285
Average power
consumption(kw)		0.5210.7311.5140.4830.6471.158
Maximum power
consumption(kw)		1.7382.4385.0461.462.1543.858
Resolution1920x10801920x10803840x21601920x10803840x21603840x2160
Contrast6500:115000:1
Grayscale14bit13~16bit
Speaker unit4 full range units + 2 low frequency units
Speaker maximum power120w
Max. sound pressure level95dB
Audio frequency domain60Hz~20kHz
Refresh Rate3840Hz
Brightness100~600cd/㎡(Adjustable)
Viewing Angle(H/V)160°/140°165°/165°
Input and output interfaceInput:HDMI2.0 *1,HDMI1.4 *3,USB2.0 *1,USB3.0 *2,Type-C *1,POE *1,RJ45 *1,3.5mm Audio in *1,RS232 *1
Output:HDMI2.0 *1,3.5mm Audio out *2,USB *1
Operating systemAndroid13.0,8G + 64G,Cortex-A76 ×4 + Cortex-A55 ×4
Optional Windows System
Cabinet materialDie-casting magnalium
Installation methodMobile Stand , Wall mounting, Ceiling-hanging
Maintenance methodFront-maintenance
Recommended viewing
distance(m)		≥3.2≥3.8≥5.0≥3.2≥1.9≥2.5
