Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Foodstuff Industry Corn Mill 15mm Powder Grinder Machine
Specifications
Brand Name :
Brightsail
Model Number :
BS
Certification :
CE ISO
Place of Origin :
China
MOQ :
one set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20 sets per month
Delivery Time :
30-35 days
Packaging Details :
Container
Product name :
industrial corn grinder
Application :
agricultural products of oil and fat and chemical raw materials
Material :
SS 304/316
Capacity :
60-700kg/hr
Fineness :
40-1000 mesh
Feed size :
<15 mm
After-sales services :
Provided
Door disc crush motor(kw) :
15-30
Name :
corn crusher
Description

Foodstuff Industry 60 To 700 Kg Per Hr Capacity Industrial Corn Mill

Product Introduction:

BSZ Pin mill can be used in food, pharmaceutical, chemical and other industries, mainly for grinding. For high oil content materials, such as coffee beans, caraway seeds, this type can also have a good grinding effect. In the production of fruit powder, liquid nitrogen is needed to control the temperature of grinding chamber so as to keep the yield of fruit powder in good condition. For Eggshells, this type of needle mill is also suitable. This product conforms to the food safety standard, easy to operate, low noise. There are two types of grinding wheel grinding and one-way grinding wheel grinding.

Technical data:

Model BSZ-350 BSZ-450 BSZ-550
Capacity(kg/h) 60-200 150-500 230-700
Feed size(mm) <15 <15 <15
Output size(mesh) 40-1000 40-1000 40-1000
Cavity disc crush motor(kw) 18.5 22 37
Door disc crush motor(kw) 15 18.5 30
Feed screw motor(kw) 0.37 0.55 0.75
Speed(rpm) 12000 9600 8400

Working method:

The machine adopts the method of quantitative feeding to control the even movement of material in the grinding block. The method of negative pressure traction is adopted for unloading. The machine has no screen, and the fineness of grinding materials can be adjusted by the speed of grinding wheel. It can also be graded by external grading.

Main components:

1. Crusher: there are 2 grinding plates, which are faster and finer than the powder ground by ordinary crusher.
2. Cyclone part: it can separate the dust in the powder (particle).
3. Pulse dust collector: remove dust inside the dust collector. There are many dust collection bags in the box, and the bag rack is also made of stainless steel for easy disassembly. Pulse jet cleaning is adopted, which is convenient to collect dust.

Main features:

1) High rotary speed, up to 12000rpm

2) No need sieve or screen mesh in mill chamber, changing powder size by changing rotary speed.

3) Very suitale for some materials with high oil content, such as cocoa, coffee bean.

How Can I Buy This Machine?
First of all, discuss all machines details and price with our sales person.
Secondly, confirm the price and payment terms Trade assurance/TT/Escrow/Western Union etc.
Thridy, send us purchased order and confirm our Proforma Invoice and arrange deposit. Once well received the deposit, we will arrange production.
At last, please arrange balance payment for us once machine is ready, then we will arrange shipment booking after received the balance payment and shipping the machine to you.
