Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
Specifications
Brand Name :
Rongsheng Xinwei
Model Number :
Rongsheng
Certification :
ISO9001
Place of Origin :
Zhengzhou ,China
MOQ :
1 Ton
Price :
200-800USD
Payment Terms :
TT; L/C
Supply Ability :
2000tons /month
Delivery Time :
20-30 Days
Packaging Details :
Packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages
Description
Rongsheng Factory Good Price Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
Alumina Insulating Refractory Bricks can serve as a flame-contacting working layer or as an insulating layer. They are widely used in ceramic and refractory kilns, powder metallurgy sintering furnaces, semiconductor firing kilns, and kilns with hydrogen or reducing atmospheres.
Alumina Hollow Ball Bricks also named Alumina bubble brick, is based on the alumina hollow ball and alumina powder as the main raw material. They are mainly used as the lining of high-temperature industrial furnaces operating below 1800°C and as the insulation layer for thermal equipment.
Alumina hollow balls are a new type of high-temperature insulating material. They are made by melting industrial alumina in an electric furnace and blowing it into hollow spheres of a-Al2O3 microcrystals. Products made primarily from alumina hollow balls can be formed into various shapes, with a usage temperature of up to 1800°C. These products have high mechanical strength, several times that of typical lightweight products, while their bulk density is only half that of corundum products. They have been widely used in high-temperature and ultra-high-temperature furnaces such as petrochemical gasification furnaces, carbon black reactors, and induction furnaces in the metallurgical industry, achieving highly satisfactory energy-saving results.
The production process of alumina hollow ball bricks involves melting alumina raw materials in a tilting electric furnace, where the liquid flows from a pouring spout at a controlled speed. The liquid stream passes through a flat nozzle at an angle of 60°-90° and is blown into hollow balls by a high-velocity airflow at a pressure of 0.6-0.8 MPa. These hollow balls, combined with sintered alumina fine powder and binders in specific proportions, are shaped, dried, and fired to produce alumina hollow ball bricks.
Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
The physical and chemical properties of alumina hollow ball products are as follows:
Item Alumina Hollow Ball Bricks Zirconia Hollow Ball Sialon-Bonded Al2O3 Hollow Ball Brick
LKZ-88 LKZ-98 ZKZ-98 --
Service Temperature (°C) 1650 1800 2000～ 2200 1600
Al2O3 , % ≥ 88 99 - 70
ZrO2 , % ≥ - - 9.8 -
SiO2 , % ≤ - 0.2 0.2 -
Fe2O3 , % ≤ 0.3 0.15 0.2 N≥5
Bulk Density (g/cm³) 1.30～1.45 1.40～1.65 ≤ 3.0 ≤ 1.5
Cold Crushing Strength (MPa) 10 9 8 15
Refractoriness Under Load (°C) 1650 1700 1700 1700
(0.2MPa,0.6%)≥
Permanent Linear Change (%) ±0.3 ±0.3 ±0.2 -
1600℃×3hrs
Thermal Expansion Coefficient (10⁻⁶/°C) ～8.0 ～8.6 Thermal Shock Resistance Thermal Shock Resistance,次
(Room temperature, ~1300℃) (1100℃ water cooling)≥15
Thermal Conductivity,W/(m.K),≤ 0.9 1 0.5 1.1
(Average 800℃)
Applications Used as thermal insulation lining for carbon black furnaces in petrochemical industry, and lining for high temperature kilns such as ceramics and refractory materials. Used as thermal insulation lining of carbon black furnaces in petrochemical industry, thermal insulation lining of gasification furnaces and gasification furnaces, and lining of high-temperature kilns such as ceramics and refractory materials. It is used for firing hard and super-hard alloy vacuum medium frequency ultra-high temperature furnace lining and insulation layer. It can also be used for lining of other ultra-high temperature furnaces with a temperature of 2000-2200℃.
Wholesale Alumina Bubble Bricks Alumina Hollow Ball Insulating Brick
