Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance
Specifications
Brand Name :
Halstec
Model Number :
Roller Crusher
Place of Origin :
CHINA
Certification :
ISO9001
MOQ :
1 Set
Price :
Negotiation
Packaging Details :
Nude in the container
Delivery Time :
60-70 days after advanced payment
Payment Terms :
L/C, T/T or negotiation
Supply Ability :
2-5 sets per month
Customized :
Customized
Model :
GS1000X1000
Brick Type :
Red Clay Bricks, Porous Bricks, Hollow Brick, Etc.
Feature :
Easy Operation
Power :
45+55kw
Capacity :
≥60 M³/hr
Material: :
High-quality Steel
Function :
To Further Crush Raw Materials Into Particle Size Of ≤ 2mm
Description

Product Description:

The double crusher (also known as a twin roll crusher) is a key crushing equipment in brick and tile production lines. Located after primary crushing equipment (such as jaw crushers), it is mainly used for medium and fine crushing of raw materials such as shale, coal gangue, clay, and limestone.
This equipment utilizes two opposing rotating rollers to crush materials to the required particle size through low-speed extrusion, ensuring that the raw material particles are ≤2-3mm. This provides qualified fine feedstock for subsequent mixing and extrusion molding, playing a crucial role in improving brick quality and yield.

Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance

Features:

-Uniform and controllable output particle size: The gap between the two rollers can be precisely adjusted (1-30mm), resulting in stable finished particle size and low over-crushing rate.
-Suitable for wet and sticky materials: Low-speed operation; the roller surface structure is reasonably designed, making it less prone to clogging when processing raw materials with high moisture content such as coal gangue and shale.
-Smooth and low-noise operation: Utilizes a low-speed extrusion crushing method, resulting in low vibration and noise, and a friendly working environment.
-Low power consumption: Compared with other crushing methods, it has lower unit energy consumption and significant energy-saving effect.
-Easy maintenance: Simple structure; the roller surface can be repaired by welding or the wear-resistant liner can be replaced, resulting in low maintenance costs.
-Sealed and dustproof: Equipped with an internal dustproof plate, providing good sealing performance, reducing dust, and meeting environmental protection requirements.

Technical Parameters:

Capacity ≥60 M³/hr
Material High-quality Steel
Customized Customized
Brick Type Red Clay Bricks, Porous Bricks, Hollow Brick, Etc.
Automatic Grade Automatic
Power 45+55kw
Feature Easy Operation
Function To Further Crush Raw Materials Into Particle Size Of ≤ 2mm
Model GS1000X1000
Description This Fired Clay Brick Making Machine is suitable for producing bricks with materials like refractory wool, refractory fiber, and refractory ceramic fiber insulation, ensuring high-quality and durable bricks.

Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance

Applications:

Raw materials for brick making include shale, clay, coal gangue, limestone, and fly ash.
Suitable for brittle materials with a compressive strength ≤160MPa and moisture content ≤35%.

Roller Crusher for Brick Factories – Uniform Particle Size, No Clogging or Jamming, Simple Maintenance

Structure:

The double roll crusher mainly consists of the following parts:
Rollers: Two crushing rolls rotating in opposite directions, with surfaces made of wear-resistant material.
Bearing Housings: Fixed roll bearing housings and movable roll bearing housings (movable along the frame).
Adjusting Device: Wedge-shaped or shim-type, used to adjust the gap between the two rolls.
Safety Spring/Hydraulic Device: Overload protection; the movable roll retracts when encountering a hard object.
Drive Unit: Motor, reducer/V-belt drive.
Frame: Supports the overall structure.

Packing and Shipping:

Product Packaging:

The Fired Clay Brick Making Machine is carefully packed to ensure safe transportation and delivery. The main machine components are wrapped with protective materials such as foam and plastic film to prevent any scratches or damage during transit. All smaller parts and accessories are securely placed in reinforced wooden crates or sturdy cardboard boxes. The packaging is designed to be moisture-resistant and robust enough to withstand rough handling, ensuring the machine arrives in perfect working condition.

Shipping:

Shipping of the Fired Clay Brick Making Machine is arranged via reliable freight services to ensure timely and secure delivery. Depending on the destination, shipping options include sea freight, air freight, or land transportation. The machine is loaded using appropriate lifting equipment to avoid any damage. Complete documentation, including the packing list, invoice, and shipping bill, is provided to facilitate smooth customs clearance and delivery. We also offer tracking services so customers can monitor the shipment status until it reaches their location.
