Hermetically Sealed Metal Bellows Load Cell Made Of Stainless Steel Offering Load Capacity of 5-500kg (WL-129)

Product Description:

Hermetically Sealed Metal Bellows Load Cell Made Of Stainless Steel Offering Load Capacity of 5kg-500kg (WL-129)

The Bellow load cell WL-129 is also a shear beam taype load cell, working with the stain gauge technology.The beam type load cell delivers load measuring capacity ranging from 5kg-500kg,with rated output of 2.0±0.05mV/V. Made of stainless steel, the weight transducer WL-129 is hermetically sealed metal bellows with IP 68. The Bellow type load sensor WL-129 offers C3 accuracy ,mg-level resolution and strong stability properties, which make the weight sensor WL-29 suitable for various automated stamping applications.The load cell WL-129 is mainly used in platform and conveyor scales for dosing and level measurement as well as in weighing modules that, for instance are used for tank weighing applications.

In order to satisfy client needs, the stainless steel bellow load cells can also be altered or customized. At BRANS, we recognize that every application is different and needs a customized response. We can adjust our product to meet your unique needs thanks to our bespoke service, which guarantees the highest level of accuracy and dependability. We are devoted to giving you the finest possible solution for your particular application through our tailored service.

Features:

• ​Shear Beam Load Cells,Bellow Load Cells
• Made of Stainless steel
• Hermetically sealed metal bellows
• Load capacity range:5kg-500kg
• Optimized for parallel connection
• Easy to install; with compact design
• With high precision and mg-level resolution
• Mainly used for platforms and conveyor scales for dosing and level measurment
• Different cable lengths and other options deliverable

Technical Parameters:

Dimensions (Unit:mm):

Packing and Shipping:

The Load Cell will be carefully packaged and shipped to ensure its safe arrival to your location. The packaging process is as follows:

• The load cell will be placed in a sturdy cardboard box to protect it from any external damage during shipping.
• The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving around during transport.
• The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
• Additional layers of bubble wrap may be added for extra protection.
• The box will be securely sealed with tape to prevent any tampering.
• A shipping label with your address and the product information will be affixed to the box.
• The package will be shipped using a reliable and trusted courier service.

Once the package has been shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the shipping address to receive the package to avoid any delays or issues.
