Semi-Automatic Nitrogen Wiping System for Hot Dip Galvanizing Line with Steel Wire Wiping System

Specifications

Certification :

ISO, CE

MOQ :

Power Source :

Nitrogen

Automatic Grade :

Semi-Automatic

Type :

Auxiliary Equipment

Transport Package :

Water Proof

Zinc Thickness :

>80 g/m2

Nozzle Type :

Separate Nitrogen

Nozzle Design :

Fractional

Flow Control :

Separately controlled

Flow Adjustment :

Flow meter and valve

Zinc Adjustment :

Nitrogen pressure, flow, speed

Speed Range :

Middle and high

Wire Speed :

Variable per wire

Oxidation Prevention :

Zinc oxidation prevention

Zinc Consumption :

Reduced

Structure :

Reliable and delicate

Description

Steel wire Nitrogen wiping system for hot dip galvanizing line

1. Company location: Wuxi city; FOB port: Shanghai

2. ISO9001:2008 and CE certified

3. Participate actively in international competition

4. Experience: more than 20 years

5. Professional technology discussion and warm customer service

Specifications:

• Nitrogen wiping is suitable for zinc thickness >80 g/m²

• Separate Nitrogen nozzle is for each steel wire, circula wiping

• Fractional nozzle designed, can achieve continuous concentric zinc coat, operation is convenient

• Nitrogen flow is separately controlled, equipped with flow meter and flow adjusting valve, visial and adjust

conveniently

• The zinc thickess is adjusted by changing the Nitrogen pressure, flow and wire running speed

• Suitable for middle and high speed

• The speed for each wire can be different, to get differnt required zinc thickness

• Nitrogen wiping can prevent the zinc oxidation at zinc bath wire outlet, reduce the zinc consumption

• The whole structure is reliable and delicate, convenient for maintenance

Our Services

• Turnkey project

• Whole plant or workshop arrangement advise

• Machines installation and commissioning

•Train the worker how to operate the production line,and technoly and process trainging

• Documents include: Foundation drawings, machine drawings, electrical drawings; Machine list, spare parts

list; Machine operating manual(with pictures), detailed traing manual. (the above would be booked as a

delivery book, electric edition available)
