Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power
Specifications
Brand Name :
SUNTECHMACH
Model Number :
H32-3
Certification :
ISO
Place of Origin :
CHINA
MOQ :
10sets
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15000PCS/DAY
Delivery Time :
20-25DAYS
Packaging Details :
10PCS/CARTON
Product :
Plastic PPR Welding Machine with accurate ppr welding temperature
Pipes :
pp,ppr,pe,ppc pipe
Welding diameter :
20-32mm
Working temperature :
270℃
Rate power :
800w
Voltage :
220V
Frenquency :
50Hz or 60Hz
Function :
Manual welding for ppr tubes
Color :
customize
Warranty :
12 month
G.W/N.W :
22/21KGS
Carton :
10PCS/CTN
Packing size :
44.5*28.5*48cm (10PCS)
OEM :
OEM Acceptable
Description

Plastic PPR Welding machine with accurate ppr welding temperature in munafacturing price


Plastic PPR pipe welding machine Application

1. The raw material of the machine frame is aluminum, it is light but strong, is one of the best material for machine.
2. The main electrical apparatus elements are best of china, many are imported from abroad.
3. Removable PTFE coated heater with separate temperature control system, the temperature can be controlled to a minimum range.
4. The electric facer adopts reversible double cutting edge blades, which can make the cutting effect more perfect.

It is for PPR pipe welding.The machine is used for the connecting of plastic pipe, such as PP-R and PE. We have the following series: 800W for φ20mm, φ25mm, 32mm. The machine controls temperature exactly, easy and safe to use.

Plastic pipe welding machine Technical Data

Product name

 PPR welding tools
Model number HT32-3
Capacity

Die: 20-32mm (20,25,32MM)
Pipes pp,ppr,pe,ppc pipe


Plastic pipe welding machine Selling feature

Die: 20-32mm (20,25,32MM) designed for pp,ppr,pe,ppc pipe

ppr welding machine Instruction for use
1. Apply die head
Place the welding machine on the stander, chose die head according to pipe’s diameter, and fix it on the machine. In regular, the small end is at the front, the bigger end at the back.
2. Power on
Power on (make sure the power should be with leakage current protector) , the green light and the red light on, wait till the red light off and keep greenlight on, which indicates the machine enter into auto temperature control mode and the machine can be used.
Note: during the auto temperature control mode, the red and the green light will be on and off alternatively, this indicates that the machine is under control and it will not affect operating.
3. Fusion pipes
Using cutter to cut pipe vertically, push the pipe and fitting into die head without any rotation. Take them off immediately when heating time reached and insert

Caution

1. Please check the outer cover and cables of the machine first. Don’t use it if it is damaged.

2. The power supply must be earthed.

3. Water & various of kinds of liquid is prevented from entering the machine. It is prohibited to us outside on rainy days.

4. Keep tinder far away.

5. Operators are strongly suggested to wear gloves when working.

6. For the safety and good performance of the device, only professionals are allowed to open the machine or adjust temperature.

7. If indicators don’t change for long, it means the device is in unnormal working state, stop your work and turn off the power immediately.

8. Turn the machine to manufacturer of professionals for repair when it is out of work.

Other size in option

We have size of 32mm, 63mm, 110mm.

Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate PowerPlastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate PowerPlastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power

Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power

Plastic PPR Welding Machine with 20-32mm Welding Diameter, 270℃ Working Temperature, and 800W Rate Power

Service

1. High Quality Products with Competitive Price.
2. 7*24 Hour After-Sales Service with Free Technology Support.
3. All of our products support OEM, lead time within 70 days.
4. Full Set of Products Supply Chain.

FAQ

1. WHO ARE WE?

We are professional pipe machine manufacturer located in Hangzhou city of China starts from 1989, we are close to Port Shanghai, Ningbo as well as Yiwu. We mainly export to North and South America, South Asia and the Middle East countries. Our client are power tools wholesaler and company for specific construction project such as firefighting pipeline building etc.

2. HOW CAN WE GUARANTEE THE QUALITY?

We always test at least one pipe on every pipe machine before we ship out.

Some of our heavy duty models works well after even 7 or 8 years according to our client feedback, for all of our machine we offer 12 month warranty.

3. WHAT CAN YOU BUY FROM US?

All kind of pipe tools and plumbing tools, such as pipe threading machine, pipe grooving machine, pipe cutting machine, pipe hole cutter, manual pipe bender, pipe vice as well as the test pump.

4. WHY SHOULD YOU BUY FROM US NOT FROM OTHER SUPPLIERS?

We focus on quality piping tools, machinery and service. We have almost all kind of pipe tools, place order to us we can mix different models in one shipment.

5. HOW LONG IS THE LEADTIME?

Since the voltage of machine motors are customized, usually the lead time will be 10-35 days after payment.

6. HOW CAN YOU PLACE ORDER?

We accept T/T payment directly to our company account and we can also create order on the online shop site that you can pay to us by credit card.

7. HOW TO SHIP?

We ship by sea to port for bulk order and we also ship to door for small shipment.

8. WHAT IS THE MOQ?

Basically there is no MOQ required for our machines, we can ship any quantity but it is highly recommended to make order amount not less than USD2000.00, because according to our experience if the order are too small amount the sea shipping adding tariff makes it not cost-effective to buy oversea.

9. IS OEM ACCEPTABLE?

Yes. For bulk order we can make nameplate and customized packaging in client’s brand.
