LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
LY- HB-3000CB Intelligent 2 In 1 High Speed Rigid Box Making Machine Within Bubble Pressing Functions Automatic Rigid Box Making Machine No Need To Buy Another Bubble Pressing Machine
Specifications
Payment Terms :
L/C,T/T
Paper Size (Double Sheet) :
W:60-420mm L:120-700mm
Paper Thickness :
80-300g/m2
Model Number :
LY-HB3000CB
Production Speed（Single Sheet） :
25-35 Pairs/min
Air Pressure :
0.6-0.7mpa/min
MOQ :
1
Delivery Time :
15-20days
Cardboard Thickness :
1-3mm
Machine Weight :
7200kg
Finished Box Size (Double Sheet) :
L:55-450mm W:55-300mm H:12-150mm
Machine Dimension :
L8100*W6500*H3200mm
Packaging Details :
Film and plywood crate
Price :
Negotiate
Finished Box Size (Single Sheet) :
L:55-450mm W:55-300mm H:12-150mm
Supply Ability :
15 sets/month
Paper Size (Single Sheet) :
W:60-420mm L:120-700mm
Precision Accuracy :
±0.05mm
Certification :
CE
Ear Overlapping Size :
120mm
Power Supply :
380V/50HZ
Total Power :
37KW
Brand Name :
Lishunyuan
Production Speed（Double Sheet） :
60-70 Pcs/min
Place of Origin :
China
Ear Cross Ear Folding Size :
7-100mm
Description
LY-HB-3000CB Intelligent 2 in 1 High Speed Rigid Box Making Machine (with Bubble Pressing)


The LY-3000CB is an intelligent 2-in-1 high-speed rigid box making machine with built-in bubble pressing. Production speed up to 60-70 pcs/min (single side) or 25-35 pairs/min (double side) for normal operation. Suitable for smartphone boxes, cosmetic boxes, jewelry boxes, wine box covers, etc. It adopts servo control and visual positioning system to automatically complete feeding, gluing, positioning, forming, edge wrapping, and bubble pressing. Positioning accuracy ±0.05mm, change-over-time 30 minutes, dual forming stations ensure high output and stable operation.

This machine adopts servo control system and visual positioning system to realize automatic completion of paper feeding, gluing, cardboard feeding, corner pasting, positioning, box forming, edge wrapping, and built-in bubble pressing.

Key Features

  • Shortest Change-over-time, thereby saving precious machine time
  • Uses highly accurate Visual Robot arm positioning with German multiple camera system
  • Dual Forming stations for high output
  • Includes in-line Bubble pressing module
  • Production speed up to 70 pcs/min for do one size production
  • Positioning accuracy ±0.05mm
  • Change-over-time (job transfer time) in 30 Minutes
  • Suitable for mobile phone box, cosmetics box, jewelry box, wine box cover and other boxes…



Excel cut consists of following sections:

Feeder

•Feeder is controlled by a servo motor.

•Paper-feed-in overturn function.

•Big diameter pneumatic vacuum control valves.

•The rubber pressure roller for the feeding-in paper.

•Antistatic platform for paper.

•The automatic lifting function for feeding stack.

•Feeding stack auto stop when top paper in position Feeder control by servo motor.

•Independent controlled paper feeding table and independently controlled sheet roller.

•Avoid the inconsistency of the length of the paper between the two sheets.


Positioning


1. YAMAHA Robot Arm for spotting the box.

2. Camera with in 10 million Pixel tracing system,positioning accuracy can reach 0.05mm.

3. Four Cameras with robots arms working XY Spool for positioning.


Corner pasting

1. Adopt None stop top feeding suction after the box is formed: reduce labor cost for stay inline.

2. Secure it with a downward-pull suction , allowing the tray to stable fall onto the conveyor belt.

3. A dual-station belt feeding system simultaneously transports two matching boxes of different sizes to the positioning section

4.Easy to set up, tape width in 19mm


Forming Part (within bubble pressing function, no need bubble pressing machine)

1. Automatic setting by servo motor

2. Dual Station smart wrapper for increased production.

3. With a bubble pressing function, eliminating the need for a separate bubble pressing machine.

4. Virtual cam servo driving system.

5. Alarm device for collision detection.

6. Lift the box by holding the side of the box.

7. Scratch resistant for the paper.

8.The minimum forming dimensions is 45*45*15mm.

The maximum forming dimensions is 550*400*150mm,

multiple to do big size box without corner pasting machine

Technical Parameters:


Paper size

double sheet

single sheet

W :60-420mm

W :60-420mm

L :120-700mm

L :120-700mm

Paper thickness

80-300g/m2

Paper stacking Height

800mm

Grey board thickness

1-3mm



Finished box size

L: 55-450mm

L :55-450mm

W:55-300mm

W :55-300mm

H:12-150mm

H :12-150mm

Precision accuracy

±0.05mm

Ear overlapping size

7-100mm

Ear cross ear folding size

120mm

Max power

37KW

Capacity of production

25-35PCS/MIN

60-70PCS/MIN

Power Supply:

380V/50Hz

Air pressure

0.5-0.7mpa/min

Glue tank volume

50KG

Machine dimension:

L8500×W5500×H2000mm

Machine weight:

7200kg

Overall size of equipment

L8100*W6500*H3200mm
