Specifications
Brand Name :
FillPack
Model Number :
CGF32-32-10
Certification :
CE / ISO9001 - 2008
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T,
Supply Ability :
20Sets Per Months
Delivery Time :
25 Working Days After Deposit
Packaging Details :
wooden case package
bottle type :
glass bottle
capacity :
10000BPH
Filling heads :
32
Capping heads :
10
Washing heads :
32
Product name :
drink bottling machine
Fillling material :
non gass liquid
Material :
stainless steel
Description

PLC control stainless steel level adjusted drink bottling machine for non gass liquid​

Drink bottling machine---Main introduction

Drink bottling machine, integrating with washing, filling and capping, it realizes full automation in the whole process, suitable for glass bottle and pulling cap filling of wine, grape wine and sauce.

The bottle types applicable for various parts are easily, conveniently and rapidly adjustable. It adopts new negative pressure filling way. Compared with the machines of the same specification, the productivity and benefit of this machine is more larger.

The machine adopts advanced MITSUBISHI PLC to control the automatic running of the machine. The input bottle chain adopts speed control by frequency variation; the output bottle chain adopts adjustable speed way, which combines with the transducer of the host machine making the output bottle running more stable and reliable.

The photoelectrical inspection of the running condition of various parts makes a higher automation and convenient operation.

Drink bottling machine---Machine parameter

Washing Workstation

32

Filling Workstation

32

Capping Workstation

10

Production Capacity

10000B/H (500ml)

Machine Power

7.5kw

Machine Weight

5000Kg

External Dimensions (L*W*H)

3200*2580*2000

Drink bottling machine---Technique Parameters

Model

CGF18186

CGF24248

CGF323210

CGF404012

CGF505015

Heads

18-18-6

24-24-8

32-32-10

40-40-12

50-50-15

Production Capacity: (b/h) 500ml

6,000

10,000

15,000

18,000

24,000

Suitable Bottle Shape (mm)

Φ=50-108 H=170-340 V=330ML-2.5L

Rinsing Pressure kg/cm²)

2-3

Motor Power (kw)

3.5

4.0

5.0

7.5

9.0

Dimension (mm)

2520*2020*2700

3000*2200*2800

4160*2860*2900

4550*3250*2900

5620*3570*2900

Weight (kg)

3,500

5,500

8,000

10,000

12,000
