Specifications
Brand Name :
PINCHI
Place of Origin :
FOSHAN
MOQ :
1SET
Price :
10000-20000USD
Payment Terms :
T/T
Supply Ability :
20SETS
Delivery Time :
30WORK DAYS
Packaging Details :
WOODEN BOX
Certification :
CE
Features :
The equipment is of medium size, with quick changeovers and adjustments.
Automatic Grade :
Automatic
Sorting method :
Vertical-alignment packaging, bottle feeding, automatic bag supply
Scope of Application :
Suitable for 2-20L bottle sizes across various industries
production capacity :
Taking 2L bottles as an example, production capacity is typically around 3,000 to 4,000 bottles per hour.
Packing details :
export standerd wooden case
Maximum power consumption :
4KW/H
Warranty :
1 Year
Description
39-11SC/16SC Automatic Bottle Packaging Machine
Equipment Characteristics of Bottle Packaging Machine

This medium-sized automatic Bottle Packaging Machine features quick production changeover and easy machine adjustment. With vertically arranged encapsulation and bottle conveying system, it automatically supplies bags and is suitable for all industries handling 2-20L bottles. Maximum encapsulation molding size reaches 1200mm × 750mm × 420mm. For 2L bottles, production capacity typically reaches approximately 3,000-4,000 bottles per hour.

Basic Performance Specifications of Bottle Packaging Machine
Equipment Dimensions (L×W×H): 5200+800mm × 1880mm × 2400mm
Maximum Package Size (L×W×H): 1200mm × 750mm × 420mm
Minimum Package Size (L×W×H): 500mm × 500mm × 100mm
Equipment Frame Material: 40mm × 80mm × 4.0mm Carbon Steel
Equipment Appearance: Sheet Metal Spraying Gray/White
Package Arrangement Form: Vertical Arrangement
Input Gas Source: 0.6-0.8MPa
Input Voltage: 380V 50Hz
Maximum Applicable Bottle Dimensions: Ø250mm × H420mm; L250mm × W250mm × H420mm
Minimum Applicable Bottle Dimensions: Ø40mm × H100mm; L40mm × W40mm × H100mm
Maximum Gas Consumption: 10L/min
Maximum Power Consumption: 4KW/H
Fastest Single-Row Bottle Cycle Time: 9 seconds/row
Bottle Feeding to Reverse Beat Time: 15 seconds/round trip
Docking Height of Bottle Feeding Conveyor: 1200-1000mm Adjustable
Bottle Feeding Method: Bottle Feeding
Fastest Single-Package Production Capacity: 80 bags/hour
*Actual capacity subject to packaging specifications
Product Detail Images of Bottle Packaging Machine
39SC-11SC Automatic Juice Bottle Packaging Machine for 2L-20L Bottleswith Vertical Alignment Function
Performance Features of Bottle Packaging Machine
Bag Type: Plastic Rolled Bags
Bag Supply Mode: Automatic
Bottle Jam Alarm: Yes
Card Wallet Alarm: Yes
Number of Sealing Lines: 2
Broken/Missing Bag Alarm: Yes
Bag Sealing & Tightening: Yes
Remote Communication: Yes
System Operation Authority: 3 Levels
Changeover & Adjustment Points of Bottle Packaging Machine
Bottle Infeed Channel Width: Manual
Single-Row Bottle Misalignment Correction: Automatic
Bottle Storage Area Width: Manual / Auto
Bottle Pusher Front-to-Back Position: Auto
Bottle Pusher Body Width: Manual / Auto
Upper Bag Opening Width: Manual / Auto
Upper Bag Opening Height: Auto
Lower Bag Opening Width: Manual / Auto
Lower Bag Opening Height: Auto
Bag Mouth Upper Sealing Height: Auto
Lower Bag Mouth Sealing Width: No Adjustment Needed
Bottle/Bag Pressing Height: Auto
Packaging Station Width: Manual / Auto
Bag Length Adjustment: Auto
Bag Width Adjustment: Auto
Bag Tail Upper Sealing Height: No Adjustment Needed
Lower Sealing Height at Bag Tail: No Adjustment Needed
Bag Width Adjustment: Manual
Bag Roll Material Adjustment: Mechanical Quick Manual
Bag-Out Conveyor Distance: Auto
Payment Terms & Trade Information of Bottle Packaging Machine
Product Model 39-11SC/16SC Automatic Bottle Packaging Machine
Remarks With VAT
Place of Origin Made in China
Price Validation 100 days
Payment Term T/T, 30% deposit, 70% to be paid before loading against FAT
Delivery Time 35 days after receipt of advanced payment
Warranty 1 year for complete machine, long term for software & system
Commissioning Free commissioning within 3 days (customer bears engineer's local food, accommodation, and tickets; extra time charged at USD 150/day)
After Sales Service of Bottle Packaging Machine

The overall product quality has traceability, and the product quality warranty period is 1 year, calculated from the date of equipment acceptance.
Free maintenance is provided during the warranty period. After-sales service beyond the warranty period will incur corresponding travel and material costs.
Daily operation and maintenance services: Our company provides free remote operation and maintenance online services through the Pinchi Tech AI cloud platform, particularly for system updates, algorithm settings, software adjustments, and related services.
