Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
Specifications
Voltage :
220v
Labeling accuracy :
±1mm
Driven type :
Electric
Material :
sus304
Weight :
250kg
Packaging material :
Wood
Price :
3500-5000
Payment Terms :
T/T OR L/C
Supply Ability :
50-100set per year
Delivery Time :
20-40 days
Packaging Details :
Wooden case
Automatic grade :
Automatic
Application :
Food,Medical,Beverage,Chemical,Commodity
Labeling speed :
30-120bottles/min
Type :
roundl bottle labeling machine
Brand Name :
Labelong
Model Number :
AL-100SF
Certification :
CE
Place of Origin :
China
MOQ :
One set
Description

Automatic Sticker Round Bottle/Jar/Container Pet Glass Cosmetic/Syrup/Wine Adhesive Labeling Machine


The labeling machine is specialized in round bottles. When labeling, the bottle will automatically rotate to allow the labeling device to apply the pressure for labeling. It's suitable for medicine, food, beverage and chemical industries. It can be used for plastic, glass, metal and other round containers/ bottles. Replacements of a few parts, it also can be used for square bottles.




Main Feature

1. This machine is applied to Vials, oral liquid, glue, pencils etc.
2. PLC control, full-automatic workingTouch-screen control panel, easy operate l The inaccurate labeling is eliminated because of the structure of three rollers capable of locating labeling position. Any labeling post can be realized, AB symmetric labeling, with the fixed point and position labeling (need to increase position electric eye and product positioning)
3. The machine structure adopts enhanced rigidity design, make the machine own a simple, elegant and stable appearance.
4.The machine can be assemble positioning electric eyes and pressure inflatable, greatly improving the precision of thin and transparent bottle label
5. The machine can customize production line, Stand-alone operation can add automatic feeding mechanism.
6. Sensor control, no label, machine sto
7. 304 stainless steel machine main body, aluminum frame


Specification of machine

Model AL-100SF
Labeling Speed 50-180pcs/m
Suitable to product Diameter φ8mm~30mm
Suitable to product height 25-80mm
Suitable label size 20-100mm(width)
Labeling accuracy ± 1mm
Label inner diameter 76mm
Label outer diameter 280mm
Machine Dimension 2000(L)* 780(W) * 1400(H) mm
Net Weight Around 230kgs
Power Supply 220V 50HZ can be adjustable
Power 0.5kw
Conveyor length 1.6m



Main Configuration list (depends on customer’s requirement)

1 Part name QTY Main material
Labeling head 1set AL-alloy,stainless steel,acrylic, Sponge,PU roller
Adjusting mechanism 1set AL-alloy,stainless steel Brass, Nylon
Touch screen 1 set AL-alloy,stainless steel
2 Electronics QTY Spec. or brand
Label sensor 1 set Sick
Objective sensor

PLC 1set Mitsuibishi
Touch screen 1 set
Cylinder 1 set Airtac
Main motor 1 set XINGFENG CHINA














Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle JarAutomatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle JarAutomatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar


Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar


Contact me
Automatic Pet Glass Cosmetic Syrup Adhesive Labeling Machine For Round Bottle Jar
