Earthmoving Machinery XE230C Excavator With Intelligent Operation
Earthmoving Machinery XE230C Excavator With Intelligent Operation
Earthmoving Machinery XE230C Excavator With Intelligent Operation
Earthmoving Machinery XE230C Excavator With Intelligent Operation
Specifications
Place of Origin :
China
Brand Name :
XCMG
Certification :
CE, ISO
Model Number :
XE230C
MOQ :
1pc
Price :
negotiated
Packaging Details :
Ro-Ro
Delivery Time :
in 30 days
Payment Terms :
30% deposit, balance before shipment
Supply Ability :
7000pcs/year
Product Name :
Earthmoving Machinery
Bucket capacity :
1.0m³
Operation weight :
23,520kg
Color :
Yellow
Description

Earthmoving Machinery XE230C Excavator With Intelligent Operation

Description:

An excavator is an engineering vehicle consisting of an articulated arm (boom, stick), bucket and cab mounted on a pivot (a rotating platform) atop an undercarriage with tracks or wheels. Their design is a natural progression from the steam shovel.
Specification:

XCMG Crawler Excavator XE230C.

Easy control of operating handles

Intelligent operation

Convenient and fast maintenance

Model

XE230C

Bucket capacity

m3

1.0

Standard bucket width

mm

1,260

Operation weight

kg

23,520

Dimension(in transportation)

Overall length

mm

10,160

Overall width

mm

2,990

Overall height

mm

3,050

Min. clearance

mm

485

Engine

Model

CC-6BG1TRP

Total displacement

L

6.494

Rated output power

KW/rpm

125/2100

Digging performance

Max. digging height

mm

9,670

Max. dumping height

mm

6,795

Max. digging depth

mm

6,920

Max. vertical digging depth

mm

6,165

Max. digging radius

mm

10,270

Boom deflection angle

°

Min. slew radius

mm

3,870

Min. rear slew radius

mm

2,940

Bucket digging force

kn

163

Track type

Steel

Track width

mm

600

Travel System

Track length

mm

4,255

Wheel base

mm

3,462

Track gauge

mm

2,390

Travel speed (Gear I/II)

km/h

5.5/3.5

Gradeability

%

70

Slew speed

rpm

12.1

Bulldozing plate

Bulldozing plate width

mm

Bulldozing plate height

mm

Lifting distance

mm

Hydraulic pump type

Variable pump×2

Slew motor type

Piston hydraulic motor

Travel motor type

Piston hydraulic motor

Fuel tank capacity

L

400

Hydraulic oil tank capacity

L

240

Advantages:

1. Strong, fuel-efficient, low noise powder systems
2. Easy to service and maintain
3. Intelligent operation and display
4. The cab is comfortable, safe and wide vision
5. The advanced hydraulic system
6. Rugged and high reliable
Earthmoving Machinery XE230C Excavator With Intelligent Operation
