Specifications
Brand Name :
HDT
Model Number :
TP304L
Certification :
ASME/CE / ISO /TUV
Place of Origin :
China
MOQ :
5T
Price :
100 - 1000 USD / ton
Payment Terms :
L/C, T/T
Supply Ability :
10000 ton / month
Delivery Time :
30days
Packaging Details :
Seaworthy Package
STANDARD :
JIS, AiSi, ASTM, GB, DIN, EN
MATERIAL :
TP304L
SPECIFICATION :
Carbon steel seamless Boiler Tube, cold-drawn tube, ASTM A179/seamless boiler tubes/seamless steel pipe
Package :
Standard Seaworthy Package
Processing :
Bending, Welding, Decoiling, Punching, Cutting, Moulding
Shape :
Round
Description

GRA Electric Resistance Welded ASME SA178 Carbon Steel Tube/Alloy Steel Seamless Tubes ASTM A213/SA213 T5 T9 T11

Description

We are one of the biggest manufactures of stainless steel & duplex steel & alloy steel tubes and pipes in China. With development more than 20 years.

Alloy steel tubes is a kind of steel alloyed tube with other elements in amounts of between 1 and 50% by weight to improve its mechanical properties.Alloying elements are added to achieve certain properties in the material. As a guideline,alloying elements are added in lower percentages (less than 5%) to increase strength or harden ability or in larger percentages (over 5%) to achieve special
properties, such as corrosion resistance or extreme temperature stability.

GRA Electric Resistance Welded ASME SA178 Boiler Steel Tube

GRA Electric Resistance Welded ASME SA178 Boiler Steel Tube

Specification:

Chemical composition(%):

Grade C Mn P≤ S≤ Si Cr Mo
P11 0.05-0.15 0.30-0.60 0.025 0.025 0.50-1.00 1.00-1.50 0.44-0.65
P22 0.05-0.16 0.30-0.60 0.025 0.025 ≤0.50 1.90-2.60 0.87-1.13
P5 ≤0.15 0.30-0.60 0.025 0.025 ≤0.50 4.00-6.00 0.45-0.65
P9 ≤0.15 0.30-0.60 0.025 0.025 0.25-1.00 8.00-10.00 0.90-1.10
P91 0.08-0.12 0.30-0.60 0.020/0.010 0.020/0.010 0.02-0.50 8.00-9.50 0.85-1.05
P92 0.07-0.13 0.30-0.60 0.020/0.010 0.020/0.010 ≤0.50 8.50-9.50 0.30-0.60


Mechanical properties:

Grade Tensile strength Yield strength Elongation
P11, P22, P5, P9 ≥415 ≥205 ≥30/20
P91 ≥585 ≥415 ≥20
P92 ≥620 ≥440 ≥20

Application Industries

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
