ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
Specifications
Brand Name :
HDT
Place of Origin :
Jiangsu , China
MOQ :
5T
Price :
800 - 9000 USD / ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
About 10000 ton / month
Delivery Time :
60-75days
Packaging Details :
seaworthy packing for exporting
Product Name :
Carbon Steel Seamless Boiler Tube
Application :
Tubular Heat Exchanger and Condenser
Third Party Inspection :
BV,SGS,ASP
Certificate :
ISO9001-2008, API 5L, API 5CT
Description

ASTM A210 seamless medium carbon steel boiler and superheater tubes

ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes. Seamless medium carbon steel pipe for boiler tube and boiler flue pipe, including a minimum wall thickness of the security side, the dome and the support tube and superheater tubes.

ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure

Mechanical Properties:

Grade C(Max) Mn Si(Min) P(Max) S(Max)
A1 0.27 Max.0.93 0.10 0.035 0.035
C 0.35 0.29~1.06 0.10 0.035 0.035

Chemical composition:

Grade Tensile Strength(Mpa) Yield Strength(Mpa) Elongation (%)
A1 ≥ 415 ≥ 255 ≥ 30
C ≥ 485 ≥ 275 ≥ 30

Outside Diameter & Tolerance

Hot rolled Outside Diameter, mm Tolerance, mm
OD≤101.6 +0.4/-0.8
101.6＜OD≤127 +0.4/-1.2
Cold Drawn Outside Diameter, mm Tolerance, mm
OD＜25.4 ±0.10
25.4≤OD≤38.1 ±0.15
38.1＜OD＜50.8 ±0.20
50.8≤OD＜63.5 ±0.25
63.5≤OD＜76.2 ±0.30
76.2≤OD≤101.6 ±0.38
101.6＜OD≤127 +0.38/-0.64

Wall thickness & Tolerance

Hot rolled Outside Diameter , mm Tolerance, %
OD≤101.6, WT≤2.4 +40/-0
OD≤101.6, 2.4＜WT≤3.8 +35/-0
OD≤101.6, 3.8＜WT≤4.6 +33/-0
OD≤101.6, WT>4.6 +28/-0
OD>101.6, 2.4＜WT≤3.8 +35/-0
OD>101.6, 3.8＜WT≤4.6 +33/-0
OD>101.6, WT>4.6 +28/-0
Cold Drawn Outside Diameter , mm Tolerance, %
OD≤38.1 +20/-0
OD>38.1 +22/-0

Application:

  • For high, middle, low pressure boiler and pressure purpose

Certification

ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure

ASTM A210 Condenser Seamless Boiler Steel Tube Low Pressure
