TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
Specifications
Brand Name :
HDT
Model Number :
Stainless Steel
Certification :
ASME, TUV, SGS, ABS, PED, ISO9001, Grade A
Place of Origin :
China(Mainland)
MOQ :
5T
Price :
800 - 9000 USD / ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
About 10000 ton / month
Delivery Time :
60-75days
Packaging Details :
seaworthy packing for exporting
Material :
Stainless Steel
Finishing :
Solution Annealed & Pickled
Application :
boiler&heat exchanger, energy, petrochemical, mining, food, paper, gas and fluid industry
Shape :
Welded Tube
OD :
9.5mm to 406.4mm
WT :
0.8mm to 8mm
Description

TP316 / 316L Stainless Steel Welded Tube For Mechanical And Structure Purposes




Hua Dong Energy Technology deals with stainless steel welded pipe and tube already more than 10 years, every
year sell more than 5000 tons of stainless steel pipe and tube. Our client already cover more than 45
countries. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical,
Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc.

1 . OD ( Outer Diameter ) : 9.5mm to 406.4mm

2 . WT ( Wall Thickness ) : 0.8mm to 8mm

3 . Length : According to customer's requirement

4 . Standards : ASTM A312; ASTM A269; ASTM A789; ASTM A790 etc.

5 . Process Method : ERW, EFW etc

Material Grade :

American Standard TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc
European Standard 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc
German Standard X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc

Application : a) For fluid and gas transport
b) Structure and machining
c) Heat exchanger pipes etc
Advantages : a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment

ASTM A269 Chemical Composition :

Elements 304L(wt%) S30403 304(wt%) S30400 316L (wt%) S31603 316 (wt%) S31600
(C) Carbon, max 0.035 0.08 0.035 0.08
(Mn) Manganese, max 2 2 2 2
(P) Phosphorus, max 0.045 0.045 0.045 0.045
(S) Sulfur, max 0.03 0.03 0.03 0.03
(Si) Silicon, max 1 1 1 1
(Ni) Nickel 8.0 - 12.0 8.0 - 11.0 10.0 - 14.0 10.0 - 14.0
(Cr) Chromium 18.0 - 20.0 18.0 - 20.0 16.0 - 18.0 16.0 - 18.0
(Mo) Molybdenum N/A N/A 2.0 - 3.0 2.0 - 3.0
(Fe) Iron Bal. Bal. Bal. Bal.
(Cu) Copper N/A N/A N/A N/A
(N) Nitrogen N/A N/A N/A N/A

TP316 316L Ss Stainless Steel Welded Tubing For Mechanical Structure Purposes
