ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
ASTM Industry Pickled 5mm Electric Resistance Welded Pipe
Specifications
Brand Name :
HDT
Model Number :
TP304 TP304L TP316 TP316L
Certification :
ASME, TUV, SGS, ABS, PED, ISO9001, Grade A
Place of Origin :
China(Mainland)
MOQ :
5T
Price :
800 - 9000 USD / ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
About 10000 ton / month
Delivery Time :
60-75days
Packaging Details :
seaworthy packing for exporting
Material :
TP304 TP304L TP316 TP316L
Finishing :
Solution Annealed & Pickled
Application :
boiler&heat exchanger, energy, petrochemical, mining, food, paper, gas and fluid industry
Shape :
Welded Tube
OD :
15.9mm to 406.4mm
WT :
0.89mm to 5mm
Description
Industry Weld 316 304 Ss Tube Diameter Stainless Steel Boiler Pipes Tubing Prices



Production

Stainless Steel Mechanical Properties
Grade Tensile Strength Yide Strength Elogation Hardness

Solution

Annealing
kgf/mm²(N/mm²) kgf/mm²(N/mm²) % HRB(HV) ℃
ASTM TP 304 ≥53 (515) ≥21 (205) ≥35 ≤90 (200)

1040℃-1150℃

Water Quenching
TP 304L ≥50 (485) ≥17 (170)
TP 316 ≥53 (515) ≥21 (205)
TP 316L ≥50 (485) ≥17 (170)
JIS SUS 304 ≥53 (520) ≥21 (205)

1010℃-1150℃

Water Quenching
SUS 304L ≥49 (480) ≥18 (175)
SUS 316 ≥53 (520) ≥21 (205)
SUS 316L ≥49 (480) ≥18 (175)
GB 06Cr19Ni10 ≥53 (520) ≥21 (210)

1010℃-1150℃

Water Quenching
022Cr19Ni10 ≥49 (480) ≥18 (180)
06Cr17Ni12Mo2 ≥53 (520) ≥21 (210)
022Cr17Ni12Mo2 ≥59 (480) ≥18 (180)
EN 1.4301 (500-700) ≥20 (195) ≥40

1000℃-1100℃

Water Quenching
1.4307 (470-670) ≥18 (180)
1.4401 (510-710) ≥21 (205)

1020℃-1120℃

Water Quenching
1.4404 (490-690) ≥19 (195)

Size OD Nominal Wall Outside Diameter Length Wall
1/2" (12.7) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
3/4" (19.1) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1" (25.4) 0.065" (1.65)/0.049" (1.25) +/-0.005 (0.13) +1/8" (3.18) - 0 +/-10.0%
1-1/2" (38.1) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2" (50.8) 0.065" (1.65)/0.049" (1.25) +/-0.008" (0.20) +1/8" (3.18) - 0 +/-10.0%
2-1/2" (63.5) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
3" (76.2) 0.065" (1.65) +/-0.010" (0.25) +1/8" (3.18) - 0 +/-10.0%
4" (101.6) 0.083" (2.11) +/-0.015" (0.38) +1/8" (3.18) - 0 +/-10.0%
6" (152.4) 0.083" (2.11) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
6" (152.4) 0.109" (2.77) +/-0.030" (0.76) +1" (25.4) - 0 +/-10.0%
8" (203.2) 0.109" (2.77) +0.061" (1.55)/-0.031" (0.79) +1" (25.4) - 0 +/-10.0%

Material Grade :

American Standard TP304 , TP304L , TP310S , TP316 , TP316L , TP316Ti , TP321 , TP347 , 904L , S31803 Etc
European Standard 1.4301 , 1.4306 , 1.4845 , 1.4401 , 1.4404 , 1.4571 , 1.4541 , 1.4550 , 1.4539 , 1.4462 Etc
German Standard X5CrNi18-10 , X2CrNi19-11 , X12CrNi25-21 , X5CrNi17-12-2 , X5CrNi17-12-3 , X2CrNiMo18-14-3 , X6CrNiTi18-10 , X6CrNiTb18-10 Etc

1 . OD ( Outer Diameter ) : 15.9mm to 406.4mm

2 . WT ( Wall Thickness ) : 0.89mm to 5mm

3 . Length : According to customer's requirement

4 . Standards : ASTM A312; ASTM A269; ASTM A789; ASTM A790 ect

5 . Process Method : ERW, EFW etc

ASTM Industry Pickled 5mm Electric Resistance Welded Pipe

Application : a) For fluid and gas transport
b) Structure and machining
c) Heat exchanger pipes etc
Advantages : a) Superior surface finish
b) Better mechanical property
c) More precise dimension
d) Perfect inspection method and inspection equipment
Price Item : FOB, CFR, CIF or as negotiation
Payment : T/T, LC or as negotiation
