Seamless Heat Pipe Fins Superior Self Cleaning Integrated Heat Transfer Capacity
Seamless Heat Pipe Fins Superior Self Cleaning Integrated Heat Transfer Capacity
Seamless Heat Pipe Fins Superior Self Cleaning Integrated Heat Transfer Capacity
Seamless Heat Pipe Fins Superior Self Cleaning Integrated Heat Transfer Capacity
Specifications
Brand Name :
Dehai Boiler
Model Number :
Fin tube
Certification :
ISO9001 , SGS , ABS , ASME
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
800 Tons / Month
Delivery Time :
30 Days
Packaging Details :
Seaworthy packing
Type :
Fin Tube
Pressure :
Low / High Pressure, Low / High Pressure
Fuel :
Heater Parts / Boiler economizer
Output :
Steam
Material :
Carbon Steel
Keywords :
H fin tube
Description

Seamless Boiler Air Cooler H Fin Tube For Boiler Economizer High Quality H Fin Tube heat exchanger fin tube

Seamless Boiler Air Cooler H Fin Tube Description

1. Add the heat exchange area and reduce the number of tubes, also increase the fume flow section area to reduce the fume speed and abrasion.
2. H type fin tube can be made to double H type fin tube, high rigidness to fit long tube row.
3. H type fin economizer arranged in line to make the space into many small zones, averaged air flow to reduce the abrasion.
4. With straight channel to gain the best ash-blowing effect.
5. The compact structure to reduce the weight and reduce the manufacturing cost.

Detail

1. In order to improve the heat exchange efficiency and extend surface heat transfer, H-type finned tubes have been widely used in boilers and waste heat recovery in recent years.

2. H-type finned tubes are derived largely from rectangle finned tubes. Because of their unique groove structure on the fin surface, H-type finned tubes have excellent anti-wear and anti-fouling performance.

Structure

1. Our products can be modified according to our customers' needs and the situation.we design and manufacture safe,reliable and efficient H-fin tubes.

2. DEHAI BOILER has also completed stand-alone product quality assurance systems.Production of H-fin tubes are with high heat transfer efficiency, they have flue gas resistance and are designed for a small space.

Technical Parameters

Item Base Tube O.D
(mm)		 Base Tube Thickness (mm) Fin Height (mm) Fin thickness(mm) Fin Pitch(mm)
Range 25.4 mm ~1600mm 2.5 mm ~40 mm 0.5 mm ~20.0 mm 0.5 mm ~3.0 mm 5 mm ~ 25.4 mm
Material Carbon Steel,Alloy Steel,Stainless Steel
Length 0<L≤ 12000

Product H-fin Tube
Base Pipe Welded or Seamless
Material carbon steel, alloy steel, stainless steel, non-ferrous alloys and nickel alloys.
Application H economizer,H evaporator,H superheater,H air heater and etc.
Detailed Picture
Seamless Heat Pipe Fins Superior Self Cleaning Integrated Heat Transfer Capacity
