Specifications
Brand Name :
BOCHEN
Model Number :
3386P Series
Certification :
RoHS, Reach
Place of Origin :
Chengdu
MOQ :
100 Pieces
Price :
$0.06 - $0.90/Piece
Payment Terms :
T/T, L/C, D/A, D/P, Western Union
Supply Ability :
10000000 Pieces Per Month
Delivery Time :
1-7 Workdays
Packaging Details :
1. 50 Pieces/Tube, 1K/2K/ 5K Pieces/Small Carton, 20k Pieces/Mater Carton 2. 20K Pieces/Master CTN/13.5KG/60*35*30cm.
Product Name :
3386P 0.5W 10k ohms Precision Single Turn Trimmer Potentiometer
Resistive Element :
Cermet
Mounting Style :
Through Hole
Adjustment Method :
Top Adjustment
Resistance Range :
10Ω~5MΩ
Rated Power :
70℃，0.5W；125℃，0W
Effective Travel :
220°
Resistance Tolerance :
±10%; ±20%
Terminal Resistance :
≤±1% R or 3Ω
Contact Resistance Variation (CRV) :
≤3%R or 3Ω
Total Mechanical Travel :
250°
Operating Temperature Range :
-55°C ~ + 125°C
Description

3386P Series 0.5W 10k ohms Precision Single Turn Cermet Trimmer Potentiometer

Quick Detail:

• 3/8˝ square / single turn / cermet element / fully sealed.

• Six terminal style.

• Available with extended shaft.

• Available with a knob for finger adjust.

• Top and side adjustment.

• Through hole mounting.

• Wide ohms range from 10Ω to 5MΩ, tolerance 10%.

• Electrical travel 220°, total mechanical travel 250°.

Description:

The 3386P trimmer potentiometer is an electronic component known for its adjustable resistance capabilities. Here is a brief introduction to its key features:

• Adjustable resistance: The 3386P trimmer potentiometer allows users to precisely adjust resistance levels according to specific circuit requirements, providing control over voltage, current, and signal strength.

• High precision and reliability: This potentiometer offers excellent precision and reliability in resistance adjustment, ensuring consistent and accurate performance.

• Durable construction: The 3386P trimmer potentiometer is built with high-quality materials and features a robust design, making it resistant to wear, temperature variations, and environmental factors.

• Easy installation and compatibility: It features standard pin spacing and is designed for easy installation and compatibility with various electronic systems and devices.

• Versatile applications: The 3386P trimmer potentiometer is commonly used in audio equipment, consumer electronics, industrial controls, and other applications that require precise resistance control.

In summary, the 3386P trimmer potentiometer is a high-precision, reliable, and versatile component that allows for accurate resistance adjustments in electronic circuits. Its durability, compatibility, and wide range of applications make it a preferred choice for engineers and hobbyists in various industries.

Specification:

Electrical Characteristics Nominal Resistance Range 10Ω~5MΩ
Resistance Tolerance ±10%; ±20%
Terminal Resistance ≤±1% R or 3Ω
Contact Resistance Variation (CRV) ≤3%R or 3Ω
Insulation Resistance 500 Vdc. 100 megohms min.
Withstand Voltage 101.3KPa, 500 Vac; 8.5KPa, 250 Vac
Dielectric Strength Sea Level 500 Vac(1min.)
Effective Travel 220°
Environment Characteristics Weld Heat Resistance 250ºC, 10 Sec.
Rated Power 70ºC, 0.5W; 125ºC, 0W
Temperature Range -55°C ~ + 125°C
Temperature Coefficient ±250, ±100 ppm /°C
Temperature Variation ΔR≤±3%R, Δ(Uab/Uac)≤±1%
Collision 20G, ΔR≤±1%R, Δ(Uab/Uac)≤±1%
Vibration 100G, ΔR≤±1%R, Δ(Uab/Uac)≤±2%
Electrical Endurance At 70°C 1000 hours @ 70ºC Rated Power; ΔR≤±3%R
Mechanical Endurance 200 cycles, ΔR≤±3%R
Physical Characteristics Total Mechanical Travel 250°
Starting Torque ≤25 mN.m
Clutch Torque ≤35 mN.m

Dimension:

Six terminal style:

Dimensions in mm, tolerances ±0.30 mm unless otherwise specified.

10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM

10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM10k 100k Ohm Precision Trimmer Potentiometer 3386P 0.5W ODM

Packaging:

Packaging specification: 50 pieces per tube.

Application:

• Calibration of Electronic Devices.

• Industrial Control.

• Medical Devices.

• Communication Equipment.

• Consumer Electronics.

• Aerospace.

• Automotive Electronics.

Advantage:

• Factory direct supply, no middlemen.
• Completed certificates such as RoHS, Reach, etc and best quality assurance.
• Sufficient production capacity, short delivery time.
• Professional after-sales service team.
• OEM&ODM available.
