Specifications
Brand Name :
LVJOE
Model Number :
FM1300
Certification :
ISO,CE
Place of Origin :
Hebei,China
MOQ :
1 line
Price :
US $20000-200000
Payment Terms :
L/C,T/T
Supply Ability :
10 lines per year
Delivery Time :
2 months
Packaging Details :
standard package
Application :
Make gypsum ceiling tile
Speed :
3-15m/min(sdjustable)
Laminate type :
single side or double side
Power :
100KW
Effective lamination width :
1300mm
Board feeding and releaseing mode :
Automatic/manual
Weight :
20T
Voltage: :
380V. 50HZ
Product Name :
High Quality Factory Supplier Customized Waterproof High-capacity Fully Automatic Plasterboard Drywall Machine
Keyword :
Plasterboard laminating machine
Description
High Quality Factory Supplier Customized Waterproof High-capacity Fully Automatic Plasterboard Drywall Machine
Key Specifications
Attribute Value
Application Gypsum ceiling tile production
Speed 3-15m/min (adjustable)
Laminate type Single side or double side
Power 100KW
Effective lamination width 1300mm
Board feeding/releasing mode Automatic/manual
Weight 20T
Voltage 380V, 50HZ
Product Overview

Our PVC gypsum ceiling tile production line creates environmentally friendly, lightweight ceiling boards with excellent fireproof, waterproof, and corrosion-resistant properties. The tiles feature a paper-faced gypsum core with PVC surface layer and aluminum foil backing, making them ideal for demanding environments.

Key Features
  • Daily Capacity: 7,000-12,000m² (based on 595×595×7mm boards)
  • Automation Level: Simple operation with high automation
  • Material Options: Gypsum board, PVC film, aluminum foil, and specialized adhesives
  • Customizable Dimensions: Available in 595×595mm, 600×600mm, 603×603mm, and 1200×600mm sizes
  • Surface Patterns: Fully customizable designs
Production Process Flow

Automatic feeding → dust cleaning → PVC film/aluminum foil laminating → film cutting (manual/automatic) → conveying → vertical cutting (with dust collection) → horizontal cutting (with dust collection) → small board stacking → edge sealing → stretch packing → finished products stacking

Technical Parameters
Parameter Specification
Sheet thickness 5-30mm
Laminating speed 15m/min
Speed adjustment Frequency conversion synchronous speed regulating
Electrical control PLC
Annual capacity 2-4 million m²
Compatible materials PVC baseboard, gypsum board, wood board, sectional board, PVC foam board
Comprehensive Support Services
  • Professional installation and debugging teams available
  • One-year equipment warranty with year-round spare parts supply
  • Continuous technical consultation and problem resolution
  • Assistance with import/export procedures and consignment
  • Production engineers available for operational support
  • Long-term cooperation opportunities
