ODM Candy Alu PVC Blister Packing Machine High Speed
ODM Candy Alu PVC Blister Packing Machine High Speed
Specifications
Brand Name :
LEIYUE
Model Number :
DPP-260
Certification :
CE
Place of Origin :
Shenzhen China
MOQ :
1 unit
Price :
USD22000-27000/unit
Payment Terms :
T/T
Supply Ability :
20 units per month
Delivery Time :
25-30 work days
Packaging Details :
Wooden box
Cutting frequency :
10-32times/min
Max shaping areas and depth :
240*140*26mm
Air pressure :
0.4-0.6MPa
Power supply :
380V/50Hz 8.5KW
Machine dimensions :
3500*800*1800mm
Net weight :
1400kg
Description

Candy Alu PVC Blister Packing Machine Cursor alignment sealing

The candy aluminum-plastic blister packaging machine is a type of mechanical equipment specialized in candy packaging. Its main working principle is to feed transparent blister film into the machine, and through heating molding, edge sealing and other process steps, the film is made into blister-type packaging material. Then the candy is packed into the packaging material and the sealing is completed, thus achieving candy packaging. The candy aluminum-plastic blister packaging machine has the characteristics of high efficiency and automation, which can realize fast packaging production lines and automatically complete various packaging process steps, thus improving production efficiency. At the same time, the candy aluminum-plastic blister packaging machine can flexibly adjust packaging process parameters according to different candy sizes, shapes, and packaging requirements to adapt to different packaging needs. The machine can produce beautiful and practical blister-type packaging materials, providing better packaging protection and display effect for candy products.

echnical Specifications:

Model DPP-260
Cutting frequency 10-32times/min
Capacity

Specific production capacity depends on the size of the product segment
Max shaping areas and depth 240*140*26mm
Air pressure 0.4-0.6MPa/ ≥0.3m³/min
Power supply 380V/50Hz 8.5KW
Main motor power 2.2KW
PVC hard pieces (width)260*(thickness)0.25-0.5mm
PTP aluminum foil (width)260*(thickness)0.025-0.05mm
Dialysis paper (width)260*50-100g
Mould cooling tap water or recycling water
Machine dimensions 3500*800*1800mm
Net weight 1400kg

Workflow:

Heating of PVC material→PVC blow molding→Manually placing products→Aluminum foil heat sealing→Finished product punching and cutting
