Specifications
Brand Name :
Junqi
Model Number :
JQ45BLW27-24V
Certification :
CE,ROHS, UL
Place of Origin :
China
MOQ :
5pcs
Price :
USD58-usd73.5/pc (Negotiable)
Payment Terms :
T/T,PAYPAL
Supply Ability :
1000PCS/Month
Delivery Time :
as confirmed
Packaging Details :
suite for export
Product Name :
Flat out rotor brushless dc motor
Model :
JQ45BLW27-24V
Rated Torque :
0.13 N.m
Rated Speed :
4840rpm
Rated Voltage :
24VDC
No-load speed :
6100rpm
No-load current :
less than 0.5A
Application :
Mdeical device, Robotics, new energy
Description

JQ45BLW27 24V 4840rpm 130mN.m Out Rotor Brushless DC Motor For Medical Device


Technical Parameters:


Item JQ45BLW27-24V
Rated voltage 24VDC
Rated Torque 130mN.m
No load speed 6100±10% rpm
No load current <0.5A
Rated Speed 4840rpm
Rated Current 3.26A
Peak Current 9.5A
Peak Torque 390mN.m
Back EMF 2.75Vrms/kRPM
Number of Phase 3
Number of Poles 16
Line to Line Resistance 0.56±10% ohms@20℃
Line to Line Inductance 0.27±20% mH@1kHz
Totor Inertia 181g.cm²
Weight 150g


Motor Dimensions(mm):


JQ45BLW27 24V 4840rpm 130mN.m Out Rotor Brushless DC Motor For Medical Device

3-Phase and Hall lead wire connections:

JQ45BLW27 24V 4840rpm 130mN.m Out Rotor Brushless DC Motor For Medical Device

We can supply Extra service:

If this motor do not match with your request. Please feel free to contact with us,We can make customized shaft / winding / mounting flange / cable / connector.We will works side-by-side with you and your team to design a motor that will fit the precise needs of your application. All Engineering and Support is done in-house.

Accessories service: gearbox, connector

Customized Design: Customized Winding, Customized Flange, Customized Shaft....

JQ45BLW27 24V 4840rpm 130mN.m Out Rotor Brushless DC Motor For Medical Device

Applications:


Medical: Syringe pump, X ray oncology equipment/ Collimators; CT; Medical bed, Face mask machine; Disability Equipment liquid Analyser; Physiotherapy Equipment; Injection Pump; Blood Analyser ; Biochemical Analyzer; Disability equipment lift


Textile: Embroidery Machines; Flat Knitting Machines;Screen Printing Machines;Spinning Machines;Yarn Preparation Machines.


Industrial Control: CNC; Pick and Place Machines, Carving Machine; Printer; Industrial Analyser; SMT; Engraving and Marking Equipment.


Logistics: Logistic&Storage Equipment ;ConveyorSystem; Conveyor System;Barrier Opening System;Door Opening System.


Household Electrical: Mover;Swimming Pool Cleaner;Coffee Machine; TV System


Office Automation: Printer, 3D Printer


Automobile: Seat Pump; Door System; Air Damper/Mixer; Lamp System


Bank Equipment: ATM machine


New Energy: Solar Tracking System


Robotics: Telepresence Robot; Humanoid Robot; Lawn Mower Robot; Robot Arm.


Agriculture Machinery: Fertiliser Distribution System; Harvesting Machines; Hydraulic Equipment Replacement; Precision Seed Drills; Pruning Scissors; Robotic Milking Machines


FAQ:


Q:How long is the lead time of orders?

A:Lead time : 4 weeks after receive the deposit


Q:What is your trade Assurance?

A:100% product quality protection.

100% product on time shipment protection.

100% payment protection for your covered amount.


Q: What’s Moq?

A: 5PCS. Small Order Welcome.


Q:Do You Make Customized Product?

A:Yes,We Accpet IT.


Q:About After Sale Serive?

A: After Sales Services 24/7.


Q: What should I do if I'm not satisfied with your product?

A: If there are defects in its quality, we can exchange a good one for you.

Generally, this problem is rare.


Q:What is the payment term?

A:T/T and Paypal is used more,please contact us for details


Q:What is the quality level of your product?

A:We produce good quality, refuse to produce low quality.


For more information, please contact with us via email: ivanzhu@junqitrading.com
