Dry Bath Nitrogen Evaporator The Concentrated Preparation Of Large Quantities Of Sample
Dry Bath Nitrogen Evaporator The Concentrated Preparation Of Large Quantities Of Sample
Specifications
Brand Name :
HUXI
Model Number :
MD200-1
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
7-15 days
Packaging Details :
Carton
Model :
MD200-1（12 position dry type Nitrogen evaporator）
Item No :
1007007001
Temp range(°C) :
RT+5~150
Time set :
0~99h59min
Temp control accuracy(°C) :
≤±0.5
Display accuracy(°C) :
0.1
Temperature uniformity@100°C :
≤±0.5°C
Temperature uniformity@150°C :
≤±1°C
Description

Dry Bath Nitrogen Evaporator The Concentrated Preparation Of Large Quantities Of SampleLinear Shaker

Application:

The nitrogen evaporator is mainly used for the concentrated preparation of large
quantities of samples, such as sample preparation in drug screening, hormone
analysis, liquid phase, gas phase and mass spectrometry analysis. Working
principle: By blowing nitrogen gas into the surface of the heated sample, the solvent
in the sample is quickly evaporated and separated, so as to achieve the purpose of
oxygen-free concentration of the sample and keep the sample more pure. Using a
nitrogen evaporator instead of a rotary evaporator for concentration, can concentrate
dozens of samples at the same time, greatly shortening the sample preparation time,
and has the characteristics of time-saving, easy operation, and fast.

Main Features:

Automatic fault detection and alarm function;
Standard equipped with air cavity and special
adjustable bracket;
Built-in over temperature protection device;
Instant temperature display, time decrease display;
Each purge needle can be independently
controlled, with multi-channel control switch, no
waste of gas;
The heater enables the sample to be quickly and
effectively heated to the evaporation temperature,
while the gas is blown from the gas chamber to the
surface of the solution through the gas needle to
promote rapid evaporation of the solution and
concentration of the sample;
The entire working system consists of an adjust
able gas chamber and heater;
The position of the gas needle in the air cavity can
be changed to make it suitablefor different test tube
standards. The length of the gas needle is 150mm;
The height of the air chamber can be adjusted
according to the height of the solvent liquid level.
When the toxic solvent is concentrated, the whole
system can be placed in the fume hood.
