Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction
Specifications
Certification :
CE,ISO9001:2008,High-tech enterprise
MOQ :
1
Price :
Individual quotation according to different requirements
Brand Name :
Peiyu
Model Number :
customized
Place of Origin :
China
Payment Terms :
L/C,T/T
Supply Ability :
30 pcs per month
Delivery Time :
30-40 workdays
Packaging Details :
The packaging uses new, sturdy special packaging boxes or fixed frames, which are suitable for long-distance transportation, moisture-proof, rust-proof, shock-proof, and suitable for land and sea transportation and overall lifting.
Model NO. :
SPC
Scale :
Large
Automation :
Automatic
Principle :
Shake Rotary Direct
Structure :
Tunnel
Operation :
Continuous
Energy :
Heat Sterilization
Property :
Physical Sterilization
Type :
High Voltage Electric Field Sterilization Equipment
Diameter :
DN1200
Length :
6000mm
Dimension :
6600X1500X2000mm
Material :
SUS304
Material Thickness :
8mm
Working Pressure :
0.3Mpa
Description

Product Description

Introduction to the configuration of the autoclave
The pot body is made of SUS304 stainless steel
--Double-door vertical hydraulic upper-opening structure
--basket per pot
--The insulation of the pot body is made of SUS304 stainless steel
--Using high temperature hot water to exhaust air
--All gas connections and lines required for the sterilizer are connected with open wires and outsourced cables.
--Working pressure: 0.3Mpa
--Safety device for the tank
safety valve;
safety interlock;
emergency button;
Alarm light and alarm buzzer;
alarm system;
--HMI
The sterilization status (temperature, pressure, valve status, liquid level, door opening status) can be checked at any time;
--You can edit the sterilization formula by yourself
--Use a paperless recorder to monitor and record all the processing data in the retort
Pot temperature, pot pressure, sterilization time, high and low temperature and liquid level alarm
--Automatic control of the sterilization process, dynamic tracking and recording of the operating status of the sterilizer, parameters of the sterilization process, alarm records, etc.
--Please refer to the configuration list for the detailed configuration of the wall thickness of the sterilizer process tank, valve instrument, PLC, and paperless recorder

Detailed Photos

Fully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel ConstructionFully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel ConstructionFully Automatic Highly Secure Sterilization Retort Autoclave with SUS304 Stainless Steel Construction

Product Parameters

Items unit DN1200# DN1300# DN1500# DN1600# DN1800# DN1900#
Total length mm 6600 6600 7700 7700 8800 9800
Total width mm 3500 1700 2000 2200 2400 2800
Total hight mm 2000 2200 2400 2600 2800 3000
