400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator
Specifications
Brand Name :
Bestran
Model Number :
BT-PM9B
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
USD 390 PC
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
500pcs per Month
Delivery Time :
3-5 days
Packaging Details :
Packing size:51*42.5*27cm, 1pc/carton, N.W.:5.2KG, G.W.:8.6KG
Product :
High-Frequency Electrosurgical Unit
Power :
400W
High-Frequency :
Yes
Pure cut :
1W~350W (Max. 400W, load 500 Ω);
Blend cut 1 :
1W~250W (load 500 Ω);
Blend cut 2: :
1W~200W (load 500 Ω);
ENDU Cut: :
99% (load 500 Ω);
Spray coagulation :
1W~80W (load 500 Ω);
Desicate coagulation :
1W~120W (load 500 Ω);
bipolar cutting function :
Option
Description

400W High-Frequency Electrosurgical Unit Bipolar & Monopolar Surgical Generator


High-Frequency Electrosurgical Unit Features:

  • Powerful Performance: The 400W output provides ample power for a wide range of surgical procedures, ensuring quick and effective cutting and coagulation.

  • Versatile Functionality: With both Bipolar & Monopolar modes, this unit offers flexibility for different surgical techniques. Monopolar mode is ideal for cutting and coagulation over a broad area, while bipolar is perfect for precise, localized coagulation, especially in delicate procedures.

  • Precision and Control: The High-Frequency technology allows for clean, controlled cuts and effective hemostasis, minimizing tissue damage and reducing patient recovery time.


High-Frequency Electrosurgical Unit Rated output power:


Pure cut

1W~350W (Max. 400W, load 500 Ω);
A high-frequency alternating current yields smooth, rapid cuts that evoke little to know hemostasis. (No-focus precision cutting, 100% cutting.)

Blend cut 1

1W~250W (load 500 Ω);
Preset blended cut modes give the surgeon varying degrees of hemostasis in cut mode. (Superficial focal gamma accurate cutting 80% cutting, 20% coagulation.)

Blend cut 2

1W~200W (load 500 Ω);
The mode is used for vaporization of prostatic tissue or any fat tissue. The higher output wattage gives fast cutting effect of the tissue. (60% cutting, 40% coagulation.)

ENDU Cut

99% (load 500 Ω);
The mode is used to automatically controlled cut system to reduce the complication rate of endoscopic sphincterotomy (EST) and serum hyperamylasemia after EST compared to the conventional blended cut mode.

Spray coagulation

1W~80W (load 500 Ω);
Spray output is made for direct coagulation at the tissue with spark. Above spark does not give any cutting effect as its CREST FACTOR is high. (Massive coagulation)

Desicate coagulation

1W~120W (load 500 Ω);
Coagulation in which the active electrode is in direct contact with the tissue is referred to as desiccation and is the type of coagulation used in most surgeries it ensures pinpoint desiccation with less destruction of peripheral tissue.

Standard bipolar coagulation

1W~70W (load 100 Ω);
BI-COAG - For highly precise control over coagulation process and privations of carbonization.

Power consumption of the whole machine: ≤ 1100VA. (cut function 350W);



High-Frequency Electrosurgical Unit Type:


The output of this machine is fully suspended, with two independent and isolated CF type anti-defibrillation application parts (Monopolar and Bipolar), Non-AP,Non-APG type common equipment, and 220V ± 10% or 110V ± 10% network power supply.



High-Frequency Electrosurgical Unit Function:


The 416KHz (± 10%) high frequency current generated by this machine can perform surgical operations such as cutting and coagulation of biological tissues, and has monopolar cut: pure cut, blend cut 1, blend cut 2; Monopolar coagulation: spray coagulation, soft coagulation and standard bipolar six working modes.

  • Full-function automatic power compensation.
  • The high-frequency generator has a universal endoscope interface, which is used with gastroscope, enteroscope, bronchoscope, laparoscope and other endoscopes.
  • Support bipolar closure and separation to meet the requirements of surgical bipolar treatment without sticking the negative plate.
  • Patient circuit bipolar electrode plate contact quality detection system.
  • Monopolar output can be controlled either by hand or foot, and monopolar/bipolar automatic output.
  • This machine has a power-off protection circuit, which can memorize the output set value of each function in real time.
  • Remote fault diagnosis.
  • Human voice alarm function
  • Passed EMC test.
