Specifications
Payment Terms :
T/T
Delivery Time :
5-10 working days
Place of Origin :
CHINA
Certification :
CE,ROHS
Supply Ability :
1000pcs/month
Standard :
Celsius/Fahrenheit
Accuracy :
≥2°C
Usage :
Industrial, Household
Display :
Digital
Measuring Range :
-20ºC ~ +550ºC
High Definition Display Screen :
2.8"TFT Display Screen
Field Angle :
56°× 42°
Ifov :
3.75mrad
Infrared Resolution :
256X192
Measurement Accuracy :
-15°c~550°c, ±2°c
Measurement Accuracy 2 :
-20°c~15°c±4°c
Transport Package :
Carrying Case
Trademark :
HTI
Origin :
China
HS Code :
9027509090
MOQ :
1
Price :
199
Description
Product Description

Infrared thermal imaging cameras are widely used in many fields such as medical, public security, fire protection, archaeology, transportation, agriculture and geology. It is an ideal choice for electricians and maintenance technicians to quickly locate problem areas.

Product Feature
1. 2.8-inch full-view TFT display
2. Wavelength coverage:8~14μm
3. Field angle/focus length:56°× 42°/ 3.2m
4. Center point/hot and cold spot tracking
5. Infrared image resolution: 256x192
6. Visible image resolution: 640×480
7. WIFI function
8. 0.07°C high thermal sensitivity, fast temperature capture imaging
9. 5 imaging modes
10. USB lithium direct charge
11. Images can be saved and viewed on a computer, and more than 20,000 can be saved.
Product Parameters
Model HT-06
Display screen 2.8"TFT display screen
Infrared image resolution 256x192
Visible image resolution 640×480
Focus length 3.2mm
Field angle 56°× 42°
IFOV 3.75mrad
Pixel spacing 12μm
Frame rate ≤25Hz
Focusing mode Non-heating fixed/focus lens
NETD ≤50mK @ 25°C, @ F/1.0
Wavelength coverage 8~14μm
Emissivity Adjustable from 0.01 to 1.00
Color palette Rainbow, Iron oxide red, Cold color, White hot, Black hot
Measuring range -20°C~+550°C(-4°F~1022°F)
Accuracy -15°C~550°C(±2°C/±2%);-20°C~15°C(±4°C)
Setting Unit, Language, Date, Time, Format, Auto power-off
Language Chinese, English, German, Italian
Storage capacity Built-in 4G eMMC (user available storage space is about 3G)
File format JPG/MP4
Power interface Type-C
Battery type Built-in Lithium battery
Battery capacity 2000mAh
Work temperature 0°C~45°C(32°F~113°F)
Working time 2~3 hours
Storage temperature -20°C~+60°C(-4°F~140°F)
Relative humidity 10%-85%RH(non-condensing)
Product size 96×72×226mm
Product weight 375g
Detailed Photos
