Specifications
MOQ :
2
Price :
negotiable
Brand Name :
Bestone
Model Number :
GS-100D,GS-100DDA,GS-100DAH,GS-100D2
Certification :
CE
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union
Supply Ability :
more than 200pcs per month
Delivery Time :
5-8 working days
Packaging Details :
plastic carrying case and white paper box
Magnetic Field Under Test :
DC Magnetic Field (Static Magnetic Field)
Functional Specifications :
Peak Retention GS(Gauss) /Mt (Millitesla) Can Be S
DC Polarity of Measurement :
N for Positive, S for Negative
Measuring range :
0~200mT~2000mT
Frequency range :
1Hz~400Hz,10Hz~200Hz,
accuracy :
0~100mT 2%, above 100mT 5% (measured in a uniform magnetic field)
Resolution 1 :
DC*1: 0.00~200.00mT (0.01mT) DC*10: 0.0~2000.00mT (0.1mT)
Resolution 2 :
AC*1: 0.00~200.00mT (0.01mT) AC*10: 0.0~2000.00mT (0.1mT)
Magnetic field under test 1 :
DC magnetic field (static magnetic field)
Magnetic field under test 2 :
Ac magnetic field (dynamic magnetic field)
Description
Digital Gauss Meter Models: GS-100D, GS-100DA, GS-100DAH, GS-100D2
Applications
  • Magnetic field distribution measurement on permanent magnet material surfaces
  • Interstitial magnetic field analysis in magnetic circuit structures
  • Magnetic field measurement for electromagnetic devices (iron removers, magnetic separators, magnetic chucks, electromagnets, demagnetization devices)
  • Environmental magnetic field assessment (including geomagnetic fields and residual weak magnetic fields)
Key Features
  • Portable design with wide measurement range
  • Easy operation with clear LCD display
  • Measurement/peak retention functionality
  • mT/Gs unit conversion capability
  • 200mT/2000mT range selection
Operating Principle
The tension sensor operates based on Hall's principle. The circuit utilizes low-drift amplifiers and high-stability power supply, controlled by a single-chip microcomputer, with measured values displayed on a 4½-digit LCD.
Technical Specifications
Model GS-100D GS-100DA GS-100DAH GS-100D2
Measuring Range 0mT~200mT~2000mT
Frequency Range N/A 10Hz~200Hz 1Hz~400Hz 10Hz~200Hz
Accuracy DC: 5% (uniform magnetic field) 0~100mT: 2%, above 100mT: 5% (uniform magnetic field) DC: 1%/AC: 1%, 1-400Hz (uniform magnetic field) DC: 5%/AC: 5%, 1-200Hz (uniform magnetic field)
Resolution N/A DC*1: 0.00~200.00mT (0.01mT)
DC*10: 0.0~2000.00mT (0.1mT)
AC*1: 0.00~200.00mT (0.01mT)
AC*10: 0.0~2000.00mT (0.1mT)		 N/A N/A
Magnetic Field Type DC magnetic field (static) DC magnetic field (static) and AC magnetic field (dynamic)
Functions Peak retention, Gs/mT unit conversion, DC polarity measurement (N positive, S negative)
Operating Conditions 5ºC~40ºC, 20%~80% relative humidity (no condensation)
Power Supply 4x1.5V AAA (UM-4) Batteries
Dimensions 140mm (L) × 73mm (W) × 30mm (H)
Weight 180g
Display 4½-digit LCD
Units mT/Gs
Standard Accessories
  • Main unit (1)
  • Hall sensor (1)
  • Operating instructions (1 copy)
  • Plastic carrying case (B04)
