40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
Specifications
Brand Name :
Hensghou
Model Number :
HSODM07
Certification :
ISO SGS
Place of Origin :
China
MOQ :
1set
Price :
$3999-7899 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 set per month
Delivery Time :
30-40 days
Packaging Details :
1. Standard import and export wooden case 2. According to customer requirements, the packaging method can be negotiated.
Product Name :
Konjac Oven Dryer
Temperature Range :
40-80℃
Dryer Capacity :
6000KG
Tray Material :
SS 304
Tray Number :
90 trays
Dimension(L*W*H) :
Customized
Description

40KW Dried Cassave Konjac Chips Oven Dryer Machine Vegetable Heat Pump Dehydrator

The konjac oven dryer machine adopts a high temperature resistant long-axis circulation fan, and the forced hot air heated by the electric heating pipe or the steam heat exchanger circulates in the oven, which enhances the heat transfer, improves the water evaporation rate, and shortens the drying time.

THE CABINET TRAY DRYER PARAMENTERS

Model 5HF4 5HF6 5HF8 5HF10 5HF12
Trolley 4 6 8 10 12
Tray Total 60 trays 90 trays 120 trays 150 trays 180 trays
Tray Size(mm) 1400*900 1400*900 1400*900 1400*900 1400*900
Tray Capacity (Kg) 12-20 12-20 12-20 12-20 12-20
Tray Material Plastic, Stainless Steel 304,304L,316
Drying Capacity (kg/T) 600-1000kg 1000-2000kg 1500-2500kg 1800-3000kg 2000-4000kg
Chamber Dimension (mm) 5000*2300*2000 6600*2300*2000 8000*2300*2000 7000*3300*2000 8000*3300*2000
Total Power (kw) 26kw 40kw 48kw 51.5kw 57kw

THE OVEN DRYER MACHINE USE ENVIRONMENT
1 Temperature: 0～35℃.
2 Relative humidity: ≤85%RH.
3. There is no high-concentration dust and corrosive substances around.
4. There is no strong airflow around. When the surrounding air needs to be forced to flow, the airflow should not be directly blown onto the room.

THE OVEN DRYER MACHINE FEATURES

1. Simple and flexible operation;

2. Static drying/One-time feed;

3. Suitable for drying small batches and multiple materials;

4. Suitable for brittle, sticky, small particles and whole rhizomes and pieces of materials;40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays

40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays

THE MATERIAL APPLICATION

40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays

THE COMPANY PROFILE

40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays

THE PATENT CERTIFICATE

40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays

THE SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

The Port :guangzhou or chongqin

Lead Time:

Quantity(Sets) : 1 - 5 >5

Est. Time(days): 35 To be negotiated

40KW Konjac Chips Oven Dryer Machine 6000KG Vegetable Heat Pump Dryer 90 Trays
