Specifications
Brand Name :
JINHAIHU
Model Number :
XWW-
Certification :
ISO9001
Place of Origin :
BEIJING, CHINA
MOQ :
1 set
Payment Terms :
T/T,L/C,D/A,D/P,Western Union,MoneyGram
Supply Ability :
20 sets per month
Delivery Time :
10~20 work days
Packaging Details :
Standard export wooden cases
Product Name :
Series Electronic Universal Testing Machine Designed and Manufactured to International Standards UTM
Range of speed :
0.05~500mm/min
Capacity :
5KN, 10KN, 20KN
Accuracy :
±0.5%
Screw :
High precise ball screw
Sensor :
Celtron load cell
Resolution :
1/300,000
Standard :
ISO 7500-1 ISO 572 ISO 5893 ASTM D638/695/790, etc
Description

Series Electronic Universal Testing Machine Designed and Manufactured to International Standards UTM




Product pictures

Series Electronic Universal Testing Machine Designed and Manufactured to International Standards UTM

Introduction to XWW Series Computerized Electronic Universal Testing Machines

The XWW Series Computerized Electronic Universal Testing Machines are designed and manufactured in strict compliance with international and national standards, including ASTM, ISO, DIN, and GB.

This series is applicable to a broad spectrum of materials, supporting key mechanical tests such as tensile testing, compression testing, bending testing, shear testing, and low-cycle fatigue testing. It is suitable for testing metals, rubber, plastics, springs, textiles, and various industrial components.

Widely utilized across its target industries, the XWW Series also serves as an essential testing tool in research and development (R&D) institutions, professional testing laboratories, and technical training centers.


Maintechnical parameter of Computer Controlled Electronic Universal Testing Machine/UTM:

Model XWW-5, 10, 20KN
Type Door model
Max. Load 5KN, 10KN, 20KN
Unit Switchover Tone,Kg,g,Kn,Lb; mm,cm,inch
Accuracy Grade 0.5%
Force-measuring Range 0.4%~100%FS
Force-measuring Accuracy ≤0.5%
Deformation-measuring Range 2%~100%FS
Deformation-measuring Accuracy 1%
Crossbeam Displacement Resolution 0.001mm
Crossbeam Speed Range 0.01~500mm/min
Displacement Speed Accuracy ≤ 0.5%
Test Width 400mm (or according to order)
Tensile Space 600mm
Compression Space 900mm (or according to order)
Clamps Wedge Grip,Compressing Attachment,Bend accessorises
PC System Equiped with brand computer
Flat-specimen thickness

0~7mm
Power Supply AC220V
Standards

ISO 7500-1 ISO 572 ISO 5893 ASTMD638695790
Size of the host 860*560*2000mm
Weight 400Kg


Introduction of the UTM software:

Universal Testing Machine Software (Key Features)

This software boasts robust functionality, encompassing dedicated test programs for tensile testing, compression testing, bending testing, shear testing, and peel testing on metallic, non-metallic, and various other materials.

  • User-Friendly Platform: Windows-based, featuring intuitive operation and easy-to-learn functionality for streamlined user adoption.
  • Multilingual Support: Supports seamless language switching between Simplified Chinese, Traditional Chinese, and English.
  • User Management: Accommodates up to ten user accounts with password protection for secure access control.
  • Overload Protection: Integrates an overload protection function with user-configurable overload thresholds.
  • Unit Flexibility & Real-Time Monitoring: Enables effortless switching of force and displacement units, with real-time display of stress and strain variations.
  • Curve Versatility: Supports on-demand switching between multiple test curves, including load-displacement, load-time, displacement-time, stress-strain, and load-tensile length curves.
  • Force Calibration System: Equipped with a dual-channel force value calibration system, featuring automatic zero-setting and automatic identification/import of calibration data.
  • Standard Compliance: Compatible with numerous international and national testing standards, such as ISO, JIS, ASTM, DIN, and GB.
  • Curve Comparison: Facilitates comparative analysis of test curves within the same group via overlay display.
  • Automatic Calculation: Includes automatic zero-setting, with automatic computation of key parameters: maximum force, upper yield strength, lower yield strength, tensile strength, compressive strength, elastic modulus, and elongation percentage.


Series Electronic Universal Testing Machine Designed and Manufactured to International Standards UTM

Series Electronic Universal Testing Machine Designed and Manufactured to International Standards UTM


System configuration:

1 Machine main unit

1.1 AC servo motor, driver 1 set

1.2 Speed reduce system 1set

1.3 Load cell 5, 10, 20KN 1pc

1.4 Precision precision ball screw 2sets

1.5 Control board 1set

2 Servo control system 1set

3 Gear system 1set

4 PC 1set

5 Inkjet color printer 1set

7 Tensile test accessories 1set

Compression accessorises 1 set

Bend accessorises 1 set

8 Large extension extensometer 1 set

9 Software installation CD 1set

10 Technical documents 1set

including : Instruction Manual

Manual of the Software

Certificate

11 Tool kit 1 set
