380V 50Hz 500J Charpy Touch Screen Impact Testing Machine
380V 50Hz 500J Charpy Touch Screen Impact Testing Machine
Specifications
Brand Name :
JINHAIHU
Model Number :
JBS-500B
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
1 set
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/A, D/P
Supply Ability :
30 sets per month
Delivery Time :
10 work days
Packaging Details :
Standard export wooden case
Product name :
Touchscreen Digital Display Charpy Impact Testing Machine
Model :
JBS-500B
Impact Energy :
250 J / 500 J
Control Methods :
Single Chip Control
Minimum Reading Value :
2 J
Impact Speed :
5.4 m/s
Pre-rising Angle Of The Pendulum :
150°
Standard Specimen Dimension :
10 mm * 10(7.5 or 5) mm * 55 mm
Power Supply :
3phs, 380V, 50Hz
Description

JBS-500B Touchscreen Digital Display Charpy Impact Testing Machine

1.Application:

JBS-B Touchscreen Digital Display Charpy Impact Testing Machine is mainly used to determine the anti-impact capability of ferrous metal materials with high toughness, especially for steel and iron and their alloy, under dynamic load.

This series tester is operated semi-automatically, the pendulum of the machine can be raised or released automatically. Be applicable for continuing testing in different kinds of laboratories and other metallurgy industrial manufactories.

2.Standards:

ISO148, EN10045, ASTM E23, GB/T3808-2002 ,GB/T229-2007.

3.Technical Specifications:

Model JBS-500B
Impact Energy 250 J / 500 J
Control Methods Single Chip Control

The Distance Between The Pendulum

Shaft And Impact Point

 800 mm
Minimum Reading Value 2 J
Impact Speed 5.4 m/s
Pre-rising Angle Of The Pendulum 150°
Specimen Bearer Span 40+0.2 mm
Round Angle Of The Jaw R 1.0~1.5 mm
Round Angle Of Impact Edge

R 2.0~2.5 mm

(Special Order: R8±0.05 mm)
Angle Accuracy 0.1°
Pendulum Torque M=160.7695N.m 80.3848N.m
Standard Specimen Dimension 10 mm * 10(7.5 or 5) mm * 55 mm
Impact Pendulum Configuration

250 J, 1 PC;

500 J, 1 PC
Power Supply 3phs, 380V, 50Hz
Dimensions 2124mm * 600mm * 1340mm
Net Weight 610 KG

4. Features:

4.1.Pendulum rising, impact, free releasing is realized as automatically by micro control meter or

remote control box.

4.2.Safety pin guaranties the impact action, standard protection shell to avoid any accident.

4.3.Pendulum will automatically rising and ready for next impact action after specimen breakout.

4.4.With two pendulums (big and small), LCD touching screen display the energy loss, impact

tenacity, rising angle, and test average value, meantime the dial scale show test result as well.

4.5.Built-in micro printer to print test result.

5. Configurations:

5.1 Main Unit 1 SET
5.1.1 Operating Instrument Fixator 1 SET
5.1.2 Pendulum(JBS-500B, 500J/250J) 2 PCS
5.1.3 Span Specimen Plate (L=40mm) 1 PC
5.1.4 Specimen Centering Plate (L=40mm)(U, V) 1 PC
5.1.5 Stripping Attachment 1 PC
5.1.6 Internal Hexagonal Wrench (S=12mm) 1 PC
5.1.7 Anchor Bolts (M16*300mm) 4 PCS
5.1.8 Impact Testing Safety Guard Net 1 SET
5.2 Measurement And Control System 1 SET
5.2.1 LCD Operation Instrument 1 SET
5.2.2 High-precision Optical Encoder 1 PC
