100KG Welding Positioner Turntable 60mm For Tig Rotator
100KG Welding Positioner Turntable 60mm For Tig Rotator
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
CW
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
30 sets per month
Delivery Time :
20 working days
Packaging Details :
Wooden box
Tube diameter :
19-60mm
Protective air :
Argon
OEM :
Acceptable
Equipment name :
Tube To Sheet Butt Welding Machine , Tube To Tube Welding Machine
Cooling :
Water cooling
Guarantee :
1 year
Description

100KG Welding Positioner Weld Welding Turntable For Tig Welding Rotator

Welding rotators are a type of automatic positioner. It works in MIG/MAG, CO2, and TIG welding sources, making a set of special circumferential automatic welding systems. This system is suitable for circumferential welding accessories of automobiles and auto bike, also suitable for the making of metal parts that need a mass of circumferential welding.

Main Characteristics:

1. The headstock can be turned 90°. The principal axis can be turned random direction to fit different angles.

2. Drive by DC motor, good performance, large timing range, available for a large range of workpieces.

3. Equipped with foot pedal switch, operated conveniently.

4. Operate by one key, you only need to press the welding key after debugging, it will weld automatically.

5. Having an emergency stop function, it will stop urgently when a special situation occurs in welding processing.

6. Has welding speed display function to show current running speed.

Item Parameter
Tube to sheet connect type Tube and sheet in same level
Welder GTW400 full position program-controlled welder
Welding torch rotation speed 0.37-7.39rpm
Arc-length adjust distance 20mm
Welding torch tilting degree -10º to 30º adjustable
Welding current 300A
Welding torch code R 25
Special factor C 43
Wire feeding speed 2200mm/min
Welding wire diameter 0.8mm, 1.0mm
Protective air Argon
Cooling type Water cooling
Cooling water flow ≥450ml/min
Welded tube diameter f19-60mm
Weight 13kg
Dimension 545*292*509mm
Item Note
GT80 welding torch 1 pc
GTW400 welder 1 pc
Aluminum box 1 pc
Clamp clip 1 pc
Balancer 1 pc
Tool box 1 pc
