Standard Gantry Type Submerged Arc Welding Machine For 800mm Width
Standard Gantry Type Submerged Arc Welding Machine For 800mm Width
Specifications
Brand Name :
Friendship Machinery
Model Number :
FSM Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Delivery Time :
30 working days after down payment
Packaging Details :
Standard package
Beam width :
200-800mm
Beam height :
200-2000mm
Beam length :
4000-15000mm
Warantee :
14 month
Welder :
Include
Machine name :
H beam welding line
Description

Standard Gantry Type Submerged Arc Welding Machine H Beam Production Line​

Automatic Welding Machine

The machine is a special equipment for assembling, welding, and straightening H beam, I beam and conical I Beam.It integrates the processes completed by the three machines of assembly machine, gantry welding and straightening machine into one machine, which significantly improves production efficiency,reduces, equipment costs, saves equipment installation space, and it is the most efficient production equipment for H-beam and T-beam.
Various kinds of welding type, it can use single arc single wire welding or single arc double wire welding according to users’ requirement; it uses submerged arc welding.
Model
H Beam Assembly Welding Straightening Machine 3 functions in 1
Web height
200~2000mm
Web thickness
6~16mm
Flange width
200~800mm
Flange thickness
6~20mm
Work-piece length
12m or as user’s request
Assembly and welding speed
0.2~3m/min
Main machine power
5kW
Roller conveyor motor power
1.1kW*4=4.4kW
Flux recycling machine motor power
3*2=6kW
Pump station power
5.5kW

● Height of the web: 200-1800mm

● Thickness of the web: 6-32mm

● Width of the flange: 200-800mm

● Thickness of the flange: 6-40mm

● Length of the h beam: 4000-15000mm

Standard Gantry Type Submerged Arc Welding Machine For 800mm Width
