CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
Specifications
Brand Name :
Friendship Machinery
Model Number :
WC67Y
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
20 sets per month
Delivery Time :
25 working days
Packaging Details :
steel framework
Control system :
ESTUN E21
Bending force :
1250KN
Power :
CNC, hydraulic
Material :
High strength carbon steel
Electric components :
Schneider
Machine type :
Bending
Description

CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending

1. Standard equipment

- Estun E21NC control System

- Powered Depth Y-axis&Back gauge X-axis

- DELTA Inverter controlled back gauge

- HIWIN Ball screws & Polished rod with 0,05mm accuracy.

- Plate Support Arms

- Germany Bosch-Rexroth Hydraulic

- Germany EMB Tubing connector

- Germany Siemens Main Motor

- Tele mecanique/Schneider Electrics

- Hydraulic &Electrical overload protection

- Top and Bottom Tooling(86°,R0.6mm)

- Safety Standards(2006/42/EC)

2. Technical parameters

Model Units WC67Y-125T/2500
Maximum bended thickness mm

8(σs≤245), 5(σs≤345)
Nominal pressure kN 1250
Worktable length mm 2500
Distance between uprights mm 2020
Throat depth mm 320
Ram stroke mm 120
Maximum opening height mm 385
Gear pump Model / CP0-25-P-10R
Flow L/min 25
Pressure MPa 31.5
Ram speed Unloaded mm/s 45
Work mm/s 6
Return mm/s 55

CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending

CNC Bending Machine Amada Design , Hydraulic Press Brake For Stainless Steel Bending
