Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
Specifications
Brand Name :
FRIENDSHIP MACHINERY
Model Number :
GSJ Series
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Delivery Time :
30 working days
Packaging Details :
Standard packing
Control way :
NC
Suitable work-piece :
Carbon steel
Power :
Hydraulic
System :
E21
Warranty :
1 Year
Compensation :
No
Description

Sheet Metal Bending Machine With E21 , Hydraulic Press Brake Bending Machine

Steel Sheet Bending Machine, Aluminium Sheet Bending Machine

NC Hydraulic Press Brake

name numerical value unit name

numerical

value

 unit
Male weigh strength 800 KN Main motor model Y132M-4
Length of worktable 2500 mm power 7.5 KW

Distance between columns

of body

 2300 mm speed 1440 R/min
throat depth 300 mm Axial piston pump model 25MCY14-1B
Slider stroke 100 mm flow 25 L/min
Open height 320 min-1 pressure 31.5 Mpa
Slider travel speed No-load 60 mm/s Shape size length 3050 mm
Work travel 12 mm/s width 1400 mm
Return trip 75 mm/s high 2300 mm

Hydraulic Press Brake Bending Machine Sheet Metal Bending Machine With E21
