5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
5T Automatic Pipe Welding Positioner , Floor Type Turntable Positioner For Welding
Specifications
Brand Name :
Friendship Machinery
Model Number :
WP
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
50 sets per month
Delivery Time :
25 working days
Packaging Details :
steel framework
Servo motor :
Made in China
Loading capacity :
1000-20000kgs
Control way :
Wireless panel
Chuck :
Option
Electric components :
Schneider
Rotation speed :
according to motor capacity
Description

1. Simple introduction

This machine is a kind of our advanced welding positioner equipment, which is be researched and manufactured absorbing domestic and international advanced positioner equipment.

The worktable is tilted by motor, accurate and reliable positioning. It makes the work-piece in perfect position for welding. The worktable adopts AC frequency conversion speed, so large range of variable speed and high precision, weld at need speed. Accordingly this device has advantages of compact structure, small cubage, beautiful shape, lightweight, convenient operating and so on. The machine can assort all kinds of auto welding or manual welding, improving welding quality, lessening welding labor and improve productivity.

This machine can be used at automatic welding or manual welding, such as pipe horizontal welding, tube end welding, axle, tray and barrel, it can be widely used in the pressure vessels equipment, metallurgy, electric power, chemical machine industry etc.

2. Technical parameter

No. Item Specification
1 Loading capacity 3000kgs 5000kgs
2 Power Rotation motor 1.5KW 2.2KW
Tilt motor 2.2KW 3KW
3 Maximum gravity height 300mm
4 Maximum centroid eccentricity 200mm

5

Working table

 Diameter 1400mm 1500mm
Rotation speed 0.05-0.5rpm
Tilt speed 0.23rpm 0.14rpm
6 Tile angle 0-120 degree
7 Package dimensions 2100*1500*1350mm 2200*1500*1450mm
8 Weight 2500kgs 3700kgs
9 EXW PRICE USD5,800 USD7,500
