H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure
Specifications
Brand Name :
Friendship Machinery
Model Number :
DX Series
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 set
Delivery Time :
30 working days after down payment
Packaging Details :
Standard package
Description

CNC H Beam / Box Beam End Face Milling Machine High Efficiency

1. Simple introduction

This machine is used for the end-face milling of welded H-beam or rolled H-beam and box-beam. Also it can be used for the others material part end-face milling, which has the good character as convenience operation, simple structure and high efficiency, etc.

2. Technical specifications

Model

DX-0810

DX-1212

DX-1215

End-face Machining rage (mm)

800*1000

1200*1200

1200*1500

Horizontal milling speed (mm/min)

50-440

50-440

50-440

Vertical milling speed (mm/min)

22-550

22-550

22-550

Milling angle (°)

0-45

0-45

0-45

Milling head size

TX25A

TX32A

TX32A

Milling facer rotation speed (rpm)

125-800

125-630

125-630

Suitable milling facer diameter (mm)

125-250

125-360

125-360

Equipment size (mm)

3600*1000*2640

3900*1200*3040

4200*1200*3040


H Beam / Box Beam End Face CNC Milling Machine High Efficiency Simple Structure

We can do the machine totally according to the size of your H-beam steel.
