60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
Specifications
Brand Name :
Allwin
Model Number :
HZPLUS60
Certification :
ISO9001
Place of Origin :
Chongqing,China
MOQ :
1 unit
Price :
USD 220000-300000Per Unit
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
30 Units per Month
Delivery Time :
90-120 Working Days
Packaging Details :
Wooden Boxes
Inner Chamber Matrial :
SIC Ceramic
Outter Chamber Material :
SUS 304 Stainless Steel
Effective Volume :
60Liter
Motor Energy :
37 KW
Ex-proof Performance :
Explosion-proof
Feed pump :
1"ARO Pump
Discharging manner :
Dynamic Discharge
Screen ring :
0.3-0.05mm
Description

60L Medical Grade Stainless Steel Horizontal Sand Mill Machine For Medical Capsule Coat Grinding

Medical capsule coat grinding are usually produced by horizontal bead /sand mills with medical grade stainless steel, to ensure the safety and non-pollution. Our machines can help users save enegry more than 50%, 2 times of production capcity.

1. Technical data of horizontal sand mill

No Main Parameters HZPlUS50/60 bead mill Notes
1 Motor power
(kW)		 30/37KW Ex-proof/non ex-proof available
2

Effective volume of

grinding chamber (L)

 50/60L volume can be suggested according to different grinding materials and usages
3 Water pressure
(MPa)		 0.3
4 Cooling water consumption (L/min) 2.5-3.0m3/h Advision: Users offer the Cooling water less 10°C
5 Dimensions:L*W*H
(mm)		 2040*1200*1840
6 Weight
(kg)		 About 1600-2000
2. Configuration Instructions
1.inner chamber material: 316L stainless steel, 304 stainless steel; SIC ceramics
2.outer chamber material: 304 stainless steel
3.dispersing shaft: 40Cr with hard chromium plating, brand: NSK
4.dispersing system material: 304 stainless steel, 316L stainless steel
5.feeding and discharging end covers: 304 stainless steel
6.discharging mode: dynamic-axis center discharging
7.mechanical sead: double end mechanical seal, with patent technology,on the side of lower pressure
8.feeding pump: 1" puenmatic diaphragm pump, Ingersoll Rand
The Dispersing system, could used different materials according to the product's demands.
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding

3.The main processing equipment:

The United States imported four axis Haas machining center

60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding

Quality control

serriously control the qultiy of purchasing parts and serriously check the quality of producing in the process

60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding

4. Exhibition show
we also positively particaipate in different industries meetings and exhibitions to show our allwin company to customers, to learn more information to make progress.
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding
customers are usually invited to our factory to chech our producing capacity, quality control, etc.
60L Medical Grade Horizontal Sand Mill Machine Medical Capsule Coat Grinding

5.The After sales service:

1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.

2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need, arrange maintenance engineer for you.

6.The package and shipping: Be covered with anti-abrasion film and then packed in wooden boxes, then seashipping by FCLor LCL.

If any detailed information and price ,pls contact me, also warmly welcom to visit us.
