Specifications
Brand Name :
BDINDUSTRIAL
Certification :
ISO,CE
Place of Origin :
China
Payment Terms :
T/T,L/C,D/A
Model Number :
Cable tray-003
MOQ :
100m
Price :
5-20 usd per meter
Supply Ability :
10000m per week
Description

1. Company Overview

Bending Stainless Steel Cable Tray is a specialized manufacturer with over 10 years of experience in the stainless steel cable tray industry. The company has strong expertise in the machinability, welding, and surface treatment of stainless steel. With in‑house design engineers, it provides custom solutions (elbows, tees, reducers, risers) and CAD drawings for complex layouts. The company enjoys excellent recognition from domestic and international customers.

2. Basic Parameters



Parameter Value
Product Name Stainless Steel Cable Tray
Max. Length 6000 mm
Max. Width 1000 mm
Side Rail Height 50 – 200 mm
Materials 304, 304L, 316, 316L, 321, 317L, Duplex (2205)
Tray Types Solid Bottom / Ventilated Bottom / Perforated / Wire Mesh / Ladder
Certifications (partial) SGSC, ISO, TUV, UL, NEMA (for perforated tray)
Keywords Stainless Steel Cable Tray

3. Material Grades & Corrosion Resistance



Grade Recommended Environment Key Characteristics
304 / 304L General industrial / indoor / chloride‑free Good general corrosion resistance, cost‑effective
316 / 316L Coastal / marine / offshore / chemical / water treatment Molybdenum (Mo) content provides excellent resistance to chlorides, pitting, crevice corrosion
321 High‑temperature areas (up to ~800°C) Titanium (Ti) stabilized, prevents carbide precipitation
317L Severe corrosion (e.g., pulp & paper, chemicals) Higher Mo content for improved pitting resistance
904L Extreme corrosive environments High Ni, Cr, Mo – excellent resistance to many strong acids
Duplex (2205) Chloride stress corrosion cracking risk areas High strength + superior chloride SCC resistance

4. Tray Types & Design Parameters



Tray Type Key Features Typical Width (mm) Typical Height (mm) Best Application
Ladder Type Good heat dissipation, easy cable laying 50 – 1200 50 – 200 Industrial plants, cable galleries
Solid Bottom (Trough) Dust & drip resistance, electromagnetic shielding 50 – 900 50 – 150 Wet/dusty areas, sensitive cables
Wire Mesh Lightweight, highly ventilated, quick installation 50 – 600 25 – 100 Data centers, office buildings, commercial spaces
Channel / Perforated Simple design, space‑saving 50 – 150 25 – 50 Machine wiring, control panels

5. Load Classes (based on NEMA VE 1 / IEEE 1222)



Load Class Side Rail Thickness (Ga/mm) Rung Thickness & Spacing Typical Applications
Light Duty (LD) ~14 Ga (~1.9 mm) Lighter rungs, spacing ≤225 mm Control/instrumentation cables (not for power cables)
Medium Duty (MD) ~12 Ga (~2.6 mm) Standard rungs, spacing ≤150 mm General industrial, mixed power & control
Heavy Duty (HD) ~10 Ga (~3.4 mm) Heavier rungs, spacing ≤150 mm Medium/high voltage power cables, long spans
Extra Heavy Duty (EHD) >10 Ga (>3.4 mm) Heavy rungs, spacing ≤75 mm Power plants, heavy industry, critical infrastructure
Vertical Tray (VTY) As MD/HD/EHD Rung spacing ≤100 mm, enhanced connections Vertical riser applications

6. Manufacturing & Quality Assurance



Item Process / Standard
Welding Process TIG welding – continuous, smooth, defect‑free seams; polished if required; minimal thermal deformation and contamination
Surface Treatment Burr‑free smooth edges; options: drawing, grinding, polishing; #4 brushed/polished finish for food/pharma to prevent bacterial adhesion
Structural Testing Load testing (vertical sag & horizontal side‑rail) per specified load classes
Material Verification Spectrographic analysis to verify stainless steel grade (e.g., 304 vs. 316)
Welding Inspection Penetration, consistency, and strength checks
Material Traceability MTC (Mill Test Certificate per ASTM A240) provided
Compliance Declaration CoC (Certificate of Conformity) provided

7. Compliance with International Standards



Standard Scope & Purpose
IEEE 1222 / NEMA VE 1 Primary U.S. standard for metallic cable tray systems – design, testing, performance
IEC 61537 / BS EN 61537 International / European standard for cable tray systems
ASTM A240 Standard specification for stainless steel plate, sheet, and strip
NEC & Local Codes Compliance with regional electrical and safety codes

8. Service & Support



Stage Service Description
Pre‑sales Support Quick response during quotation and design; professional technical engineers provide optimal project solutions
Production & Inspection Professional production line ensures consistent, on‑time delivery
After‑sales Service Prompt handling of field issues; spare parts supply; installation technical support
