25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart
Specifications
Brand Name :
BEFANBY
Model Number :
scissor lift platform
Certification :
CE,SGS,ISO9001
Place of Origin :
Henan,China
MOQ :
1 set/sets
Price :
Negotiation
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
1500 set/sets, per year
Delivery Time :
20-30 days as usual delivery
Packaging Details :
The mobile scissor lift will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Color :
Customized
Warranty :
24 months
Load capacity :
Customized
Power supply :
Battery Operated
Port :
Qingdao/Tianjin/Shanghai
Application :
Heavy industry,factory,workshop,outdoor,warehouse
Materials :
Steel
Description

25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart

Product Description

The equipment has low noise and vibration during operation, is easy to maintain, and has high safety performance. It is one of the important basic equipment for factories to achieve automated and standardized production. Depending on the use environment, the rail transporter can choose low-voltage rail power supply, cable drum power supply, busbar power supply or battery power supply to flexibly adapt to different working conditions.


25 Ton High Temperature Proof With Hydraulic Dump Function Transfer Cart

Product Parameter

Model KPT-2T KPT-5T KPT-10T KPT-16T KPT-20T KPT-25T KPT-30T KPT-40T KPT-50T KPT-63T KPT-80T KPT-100T KPT-150
Rated load(t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Heigth(H) 500 550 550 600 600 650 650 700 700 800 900 1000 1200
Wheel Base(mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rai Ilnner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Dia.(mm) Φ270 Φ300 Φ300 Φ350 Φ350 Φ400 Φ400 Φ500 Φ500 Φ600 Φ600 Φ600 Φ600
Wheel Quantity(pcs) 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed(mm) 25 25 25 20 20 20 20 20 20 20 20 20 18
Motor Power(kw) 0.8 1.5 1.5 2.2 2.5 3 4 5.5 5.5 7.5 7.5 11 15
Running distance(m) 25 25 25 25 30 30 50 50 50 50 50 50 50
Max Wheel load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Reference Wight(t) 2.5 3.5 4 5.2 5.6 6.2 6.5 7.3 7.8 10.5 12.3 14.1 26.2
Recommend Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100


QU100
