Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle
Specifications
Brand Name :
BEFANBY
Model Number :
lift platform
Certification :
CE,SGS,ISO9001
Place of Origin :
Henan,China
MOQ :
1 set/sets
Price :
Negotiation
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
1500 set/sets, per year
Delivery Time :
20-30 days as usual delivery
Packaging Details :
The movable lifting platform will be packed by the tarp, the parts will be shipped in the high quality wooden case.
Color :
Customized
Warranty :
24 months
Load capacity :
Customized
Power supply :
Battery Operated
Port :
Qingdao/Tianjin/Shanghai
Application :
aerial working,factory,workshop,construction site
Materials :
Steel
Description

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Product Description

Material transfer vehicles are highly efficient transport equipment used in workshops, production lines, and warehouse logistics. Powered by batteries, they require no external power source. They operate on custom fixed rails, ensuring smooth transport and preventing cargo from shifting or tipping over due to uneven surfaces. They also offer long battery life.


In terms of functionality, material transfer vehicles can be customized to meet user needs, including load capacity (from a few tons to hundreds of tons), vehicle dimensions, platform configuration (such as flat, recessed, or elevating), operating speed, and turning methods. Optional safety and intelligent features include wireless remote control, emergency stop, and collision avoidance.

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Product Parameter

Model KPT-2T KPT-5T KPT-10T KPT-16T KPT-20T KPT-25T KPT-30T KPT-40T KPT-50T KPT-63T KPT-80T KPT-100T KPT-150
Rated load(t) 2 5 10 16 20 25 30 40 50 63 80 100 150
Table Size Length(L) 2000 3500 3600 4000 4000 4500 4500 5000 5500 5600 6000 6500 10000
Width(W) 1500 2000 2000 2000 2200 2200 2200 2500 2500 2500 2600 2800 3000
Heigth(H) 500 550 550 600 600 650 650 700 700 800 900 1000 1200
Wheel Base(mm) 1200 2500 2600 2800 2800 3200 3200 3800 4200 4300 4700 4900 7000
Rai Ilnner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 1435 1435 1800 2000 2000
Wheel Dia.(mm) Φ270 Φ300 Φ300 Φ350 Φ350 Φ400 Φ400 Φ500 Φ500 Φ600 Φ600 Φ600 Φ600
Wheel Quantity(pcs) 4 4 4 4 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 50 75 75 75 75
Running Speed(mm) 25 25 25 20 20 20 20 20 20 20 20 20 18
Motor Power(kw) 0.8 1.5 1.5 2.2 2.5 3 4 5.5 5.5 7.5 7.5 11 15
Running distance(m) 25 25 25 25 30 30 50 50 50 50 50 50 50
Max Wheel load(KN) 14.4 25.8 42.6 64.5 77.7 94.5 110.4 142.8 174 221.4 278.4 343.8 265.2
Reference Wight(t) 2.5 3.5 4 5.2 5.6 6.2 6.5 7.3 7.8 10.5 12.3 14.1 26.2
Recommend Rail Model P15 P18 P18 P24 P24 P38 P38 P43 P43 P50 P50 QU100


QU100

Company Profile

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Product Feature

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

Shipping

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle


Related Products

Heavy Load Railway With Wireless Remote Control Material Transfer Vehicle

FAQ

1) Q: How can I operate the transfer cart ?
A: Please don't worry, dear friend. The English user manual, parts manual will be delivered with your items together.
2) Q: How to ensure your product quality ?
A : We will free provide rail installation drawing, rail foundation construction drawing, free technical guide. And if necessary,our installation engineer will go to your factory to guide the installation.
3)Q: Whether you can offer customized transfer car?
A: Yep, of course, we are manufacturer, and we have our own engineer group. They can work out customized design according to your requirement. The most important thing is that you tell us what you need.
4)Q: Whether there is professional technician assist our installation?
A :Yep. We have professional installation team, who have gone to many countries to assist the installation. If you need we send technician to your factory, please let us know in advance. So that we can arrange technicians.
