KP-1680S-Test2 Implantable Surge Tester | ISO14708-1 Compliant | KingPo

Description

Discover KingPo’s KP-1680S-Test2 Implantable Surge Tester for reliable medical device testing. Compliant with ISO14708-1 and EN 45502 standards. Request a quote today!

Product Overview

The KP-1680S-Test2 Implantable Surge Tester is a state-of-the-art solution designed for testing the reliability and safety of implantable medical devices. Engineered to simulate electrical surge conditions, this advanced tester ensures that devices such as pacemakers and defibrillators withstand real-world challenges, meeting stringent international standards like ISO14708-1:2014 and EN 45502-2-2:2008. With its user-friendly interface, robust design, and comprehensive data logging, the KP-1680S-Test2 is the ultimate choice for manufacturers and laboratories aiming to enhance patient safety and device performance.

Key Features

• Adjustable Surge Levels: Supports testing at 140V and 270V peak voltages, compliant with ISO14708-1:2014, EN 45502-2-1:2003, EN 45502-2-2:2008, and EN 45502-2-2-3:2010.
• Multiple Testing Modes: Includes positive and negative polarity testing, selectable via a front panel switch or optional computer control for automated test sequences.
• Truncated Exponential Waveform: Outputs precise pulse waveforms for defibrillation-proof testing of implantable devices, with internal resistor networks as per standard requirements.
• Fast Recharge Cycle: Recharges and triggers the next pulse in 20 seconds, ensuring efficient testing workflows.
• Comprehensive Data Logging: Records test results for thorough analysis, supporting compliance documentation and quality assurance.
• Compact and Durable Design: Measures 600×600×500 mm, built to withstand a 6-inch drop, ideal for both laboratory and field testing.
• Certified Quality: ISO9001 and CE certified, with calibration certificate included.

Applications

The KP-1680S-Test2 is tailored for:

• Implantable Medical Device Testing: Ensures pacemakers, defibrillators, and other implants meet surge resistance standards.
• Compliance Testing: Validates devices against ISO14708-1:2014 (140V peak), EN 45502-2-2:2008 (270V peak), and other EN 45502 standards.
• Research and Development: Helps engineers identify design weaknesses in implantable devices.
• Production Line Testing: Streamlines quality control for medical device manufacturers.

Technical Specifications

Why Choose KingPo’s KP-1680S-Test2?

• Standards Compliance: Meets ISO14708-1:2014, EN 45502-2-1:2003, EN 45502-2-2:2008, and EN 45502-2-2-3:2010 for reliable testing.
• User-Friendly Interface: Simplifies test setup and real-time monitoring, reducing training time.
• Robust and Versatile: Compact design suitable for lab and field use, with rugged construction for durability.
• Trusted by Industry Leaders: Backed by KingPo’s reputation, with endorsements from SGS and TÜV Rheinland. Learn more about our certifications.

How It Works

The KP-1680S-Test2 generates a truncated exponential waveform to simulate electrical surges that implantable medical devices may encounter. The tester supports:

1. Surge Simulation: Applies 140V or 270V peak surges to test device resilience.
2. Polarity Switching: Allows positive and negative polarity testing via a front panel switch or computer control.
3. Data Analysis: Logs surge parameters and device responses for compliance reporting.
4. Automated Sequencing: Optional computer control automates test sequences per standard requirements.

Order Information

• MOQ: 1 unit
• Price: $7,000 (EXW)
• Packaging: Wooden box (600×600×500 mm)
• Delivery: 30 days after payment
• Payment Terms: T/T
• Contact: Lynette Wong | sales@kingpo.hk | +86 0769 81627526
